Phoenix Contact Straight Wave Soldering Mount PCB Header, 8 Contact(s), 2.5 mm Pitch, 1 Row(s), Shrouded

View all PCB Headers

Subtotal (1 pack of 500 units)*

£668.94

(exc. VAT)

£802.73

(inc. VAT)

Add to Basket
Select or type quantity
Temporarily out of stock
  • Shipping from 16 February 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Pack(s)
Per Pack
Per unit*
1 +£668.94£1.338

*price indicative

RS Stock No.:
658-557
Mfr. Part No.:
1814906
Brand:
Phoenix Contact
Find similar products by selecting one or more attributes.
Select all

Brand

Phoenix Contact

Product Type

PCB Header

Current

6A

Pitch

2.5mm

Number of Contacts

8

Housing Material

Polyamide

Number of Rows

1

Orientation

Straight

Shrouded/Unshrouded

Shrouded

Connector System

COMBICON PTSM

Mount Type

Wave Soldering Mount

Contact Material

Copper Alloy

Contact Plating

Tin Plated

Minimum Operating Temperature

-40°C

Row Pitch

2.5mm

Termination Type

Solder

Tail Pin Length

2.1mm

Contact Gender

Male

Maximum Operating Temperature

100°C

Standards/Approvals

cULus Recognised, IEC 60068-2-70:1995-12, IEC 60512-1-1:2002-02, IEC 60512-1-2:2002-02, IEC 60512-13-5:2006-02, IEC 60512-15-1:2008-05, IEC 60512-3-1:2002-02, IEC 60512-5-1:2002-02, IEC 60664-1:2007-04, UL 94 V0, UL Recognised

Voltage

160 V

COO (Country of Origin):
CN
The Phoenix Contact PCB header is a robust and reliable solution designed to facilitate seamless connections in electronic applications. Engineered with a nominal cross-section of 0.5 mm² and crafted in a striking signal white colour, this connector ensures high visibility and easy integration into various setups. Its compact design accommodates a nominal current of up to 6 A and supports voltages rated at 160 V, making it suitable for a wide range of automation tasks. The product line incorporates a THR soldering method for simple assembly and a linear pin layout that promotes effective circuit management.

Constructed from compliant materials, catering to environmental regulations

Provides easy insertion and withdrawal, minimising installation time

Compatible with a variety of mounting techniques, enhancing versatility

Sturdy construction guarantees durability even under rigorous operational conditions
