Phoenix Contact SMSTBA 2/5-G Series Wave Soldering Mount PCB Header, 6 Contact(s), 5.08 mm Pitch, 1 Row(s), Shrouded
- RS Stock No.:
- 638-767
- Mfr. Part No.:
- 1767410
- Brand:
- Phoenix Contact
Subtotal (1 pack of 50 units)*
£137.26
(exc. VAT)
£164.71
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 16 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Pack(s) | Per Pack | Per unit* |
|---|---|---|
| 1 + | £137.26 | £2.745 |
*price indicative
- RS Stock No.:
- 638-767
- Mfr. Part No.:
- 1767410
- Brand:
- Phoenix Contact
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Phoenix Contact | |
| Product Type | PCB Header | |
| Series | SMSTBA 2/5-G | |
| Pitch | 5.08mm | |
| Current | 12A | |
| Number of Contacts | 6 | |
| Housing Material | Polyamide | |
| Number of Rows | 1 | |
| Shrouded/Unshrouded | Shrouded | |
| Mount Type | Wave Soldering Mount | |
| Connector System | COMBICON MSTB 2.5 | |
| Contact Material | Copper Alloy | |
| Contact Plating | Tin Plated | |
| Termination Type | Solder | |
| Row Pitch | 5.08mm | |
| Minimum Operating Temperature | -40°C | |
| Contact Gender | Male | |
| Maximum Operating Temperature | 100°C | |
| Tail Pin Length | 3.5mm | |
| Standards/Approvals | No | |
| Mating Pin Length | 3.5mm | |
| Voltage | 32 V | |
| Select all | ||
|---|---|---|
Brand Phoenix Contact | ||
Product Type PCB Header | ||
Series SMSTBA 2/5-G | ||
Pitch 5.08mm | ||
Current 12A | ||
Number of Contacts 6 | ||
Housing Material Polyamide | ||
Number of Rows 1 | ||
Shrouded/Unshrouded Shrouded | ||
Mount Type Wave Soldering Mount | ||
Connector System COMBICON MSTB 2.5 | ||
Contact Material Copper Alloy | ||
Contact Plating Tin Plated | ||
Termination Type Solder | ||
Row Pitch 5.08mm | ||
Minimum Operating Temperature -40°C | ||
Contact Gender Male | ||
Maximum Operating Temperature 100°C | ||
Tail Pin Length 3.5mm | ||
Standards/Approvals No | ||
Mating Pin Length 3.5mm | ||
Voltage 32 V | ||
- COO (Country of Origin):
- PL
The Phoenix Contact PCB header offers exceptional performance for a variety of electronic applications. Featuring a compact design, it integrates seamlessly into diverse devices, ensuring reliable connections. The combination of a nominal cross-section of 2.5 mm² and a maximum current of 12 A highlights its capacity to handle demanding tasks with ease. Constructed with high-quality materials, this product not only meets rigorous industry standards but also guarantees compliance with WEEE and RoHS directives.
Provides flexibility for diverse connection technologies
Compatible with the proven COMBICON system
Supports various industries, including automation and manufacturing
Reduces the risk of erroneous connections with its designed structure
