RS PRO XY2500 Series Straight Through Hole PCB Header, 5 Contact(s), 3.81 mm Pitch, 1 Row, Shrouded

RS Stock No.:: 631-123
Brand:: RS PRO

RS PRO XY2500 Series Straight Through Hole PCB Header, 5 Contact(s), 3.81 mm Pitch, 1 Row, Shrouded

Subtotal (1 bag of 10 units)*

£66.23

(exc. VAT)

£79.48

(inc. VAT)

FREE delivery for orders over £60.00

In Stock

50 unit(s) ready to ship

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Bag(s)	Per Bag	Per unit*
1 +	£66.23	£6.623

*price indicative

RS Stock No.:: 631-123
Brand:: RS PRO

Specifications

Technical Reference

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	RS PRO
	Series	XY2500
	Product Type	PCB Header
	Current	8A
	Pitch	3.81mm
	Number of Contacts	5
	Housing Material	PA66
	Number of Rows	1
	Orientation	Straight
	Shrouded/Unshrouded	Shrouded
	Connector System	Board-to-Board, Board-to-Wire
	Mount Type	Through Hole
	Contact Material	Phosphor Bronze
	Contact Plating	Nickel, Zinc
	Minimum Operating Temperature	-40°C
	Termination Type	Screw
	Contact Gender	Male
	Maximum Operating Temperature	105°C
	Standards/Approvals	ANSI-ESD S20.20:2021, CE, REACH, RoHS, UL
	Voltage	300V

	Select all
	Brand RS PRO
	Series XY2500
	Product Type PCB Header
	Current 8A
	Pitch 3.81mm
	Number of Contacts 5
	Housing Material PA66
	Number of Rows 1
	Orientation Straight
	Shrouded/Unshrouded Shrouded
	Connector System Board-to-Board, Board-to-Wire
	Mount Type Through Hole
	Contact Material Phosphor Bronze
	Contact Plating Nickel, Zinc
	Minimum Operating Temperature -40°C
	Termination Type Screw
	Contact Gender Male
	Maximum Operating Temperature 105°C
	Standards/Approvals ANSI-ESD S20.20:2021, CE, REACH, RoHS, UL
	Voltage 300V

COO (Country of Origin):: CN

RS PRO 5-Pin Shrouded PCB Header, 8 A Current Rating

This RS PRO PCB Header is designed for reliable electrical connections in various industrial applications. With a robust construction, it supports both board-to-board and board-to-wire systems, ensuring versatility and ease of integration. The shrouded design enhances safety and connection integrity.

Features and Benefits

Board-to-Board and Board-to-Wire Compatibility: Offers flexibility in design and application.
Male Contact Gender: Ensures secure and stable connections.
Phosphor Bronze Contacts: Provides excellent conductivity and durability.
Nickel and Zinc Plating: Enhances corrosion resistance and longevity.
8 A Current Rating: Suitable for medium power applications.
PA66 Housing Material: Offers high mechanical strength and thermal stability.
Wide Operating Temperature Range: Functions effectively from -40 °C to 105 °C.
Through Hole Mount Type: Facilitates easy installation and secure mounting.
3.81 mm Pitch: Ensures Compact design and efficient use of space.

Applications

Industrial automation
Consumer electronics
Telecommunications
Control systems

Additional Information

Complies with ANSI-ESD S20.20:2021, CE, REACH, RoHS, UL standards
Shrouded design for enhanced safety
Screw termination for secure and reliable connections
Rated for 300 V applications
