RS PRO XY2500 Series Right Angle Through Hole PCB Header, 4 Contact(s), 3.5 mm Pitch, 1 Row, Shrouded

RS Stock No.:: 631-118
Brand:: RS PRO

RS PRO XY2500 Series Right Angle Through Hole PCB Header, 4 Contact(s), 3.5 mm Pitch, 1 Row, Shrouded

Subtotal (1 bag of 10 units)*

£66.23

(exc. VAT)

£79.48

(inc. VAT)

FREE delivery for orders over £60.00

In Stock

50 unit(s) ready to ship

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Bag(s)	Per Bag	Per unit*
1 +	£66.23	£6.623

*price indicative

RS Stock No.:: 631-118
Brand:: RS PRO

Specifications

Technical Reference

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	RS PRO
	Series	XY2500
	Product Type	PCB Header
	Pitch	3.5mm
	Current	8A
	Housing Material	PA66
	Number of Contacts	4
	Number of Rows	1
	Orientation	Right Angle
	Shrouded/Unshrouded	Shrouded
	Mount Type	Through Hole
	Connector System	Board-to-Board, Board-to-Wire
	Contact Plating	Nickel
	Contact Material	Phosphor Bronze
	Minimum Operating Temperature	-40°C
	Termination Type	Push-in
	Contact Gender	Male
	Maximum Operating Temperature	105°C
	Tail Pin Length	6.6mm
	Standards/Approvals	ANSI-ESD S20.20:2021, CE, REACH, RoHS
	Voltage	300V

	Select all
	Brand RS PRO
	Series XY2500
	Product Type PCB Header
	Pitch 3.5mm
	Current 8A
	Housing Material PA66
	Number of Contacts 4
	Number of Rows 1
	Orientation Right Angle
	Shrouded/Unshrouded Shrouded
	Mount Type Through Hole
	Connector System Board-to-Board, Board-to-Wire
	Contact Plating Nickel
	Contact Material Phosphor Bronze
	Minimum Operating Temperature -40°C
	Termination Type Push-in
	Contact Gender Male
	Maximum Operating Temperature 105°C
	Tail Pin Length 6.6mm
	Standards/Approvals ANSI-ESD S20.20:2021, CE, REACH, RoHS
	Voltage 300V

COO (Country of Origin):: CN

RS PRO 4-Pin Shrouded PCB Header, Right Angle

This RS PRO PCB Header is designed for reliable electrical connections in board-to-board and board-to-wire applications. With a robust construction, it ensures secure connectivity and efficient performance in various industrial settings.

Features and Benefits

Board-to-Board and Board-to-Wire System: Offers versatile connectivity options for different applications.
Male Contact Gender: Ensures compatibility with corresponding female connectors.
Phosphor Bronze Contacts: Provides excellent conductivity and durability.
Nickel Contact Plating: Enhances corrosion resistance and longevity.
8 A Current Rating: Supports high-current applications effectively.
PA66 Housing Material: Offers high mechanical strength and thermal stability.
Wide Operating Temperature Range: Functions reliably from -40 °C to 105 °C.
Through Hole Mount Type: Ensures secure attachment to PCBs.
Right Angle Orientation: Saves space and allows for Compact design.
Shrouded Design: Protects contacts from damage and ensures proper alignment.

Applications

Industrial automation
Consumer electronics
Telecommunications
Automotive electronics

Additional Information

Complies with ANSI-ESD S20.20:2021, CE, REACH, and RoHS standards
Push-In Termination Type for easy installation
300 V Voltage Rating suitable for various electrical applications
Tail Pin Length of 6.6 mm for secure connections
