Phoenix Contact DMCV Series Surface PCB Header, 26 Contact(s), 2.54 mm Pitch, 2 Row(s), Shrouded
- RS Stock No.:
- 558-744
- Mfr. Part No.:
- 1845289
- Brand:
- Phoenix Contact
Unavailable
RS will no longer stock this product.
- RS Stock No.:
- 558-744
- Mfr. Part No.:
- 1845289
- Brand:
- Phoenix Contact
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Phoenix Contact | |
| Product Type | PCB Header | |
| Series | DMCV | |
| Current | 6A | |
| Pitch | 2.54mm | |
| Housing Material | Liquid Crystal Polymer | |
| Number of Contacts | 26 | |
| Number of Rows | 2 | |
| Shrouded/Unshrouded | Shrouded | |
| Connector System | COMBICON DFMC 0.5 | |
| Mount Type | Surface | |
| Contact Plating | Gold Plated | |
| Contact Material | Copper Alloy | |
| Minimum Operating Temperature | -40°C | |
| Termination Type | Solder | |
| Row Pitch | 2.54mm | |
| Contact Gender | Male | |
| Maximum Operating Temperature | 105°C | |
| Standards/Approvals | cULus Recognised, VDE | |
| Voltage | 160 V | |
| Select all | ||
|---|---|---|
Brand Phoenix Contact | ||
Product Type PCB Header | ||
Series DMCV | ||
Current 6A | ||
Pitch 2.54mm | ||
Housing Material Liquid Crystal Polymer | ||
Number of Contacts 26 | ||
Number of Rows 2 | ||
Shrouded/Unshrouded Shrouded | ||
Connector System COMBICON DFMC 0.5 | ||
Mount Type Surface | ||
Contact Plating Gold Plated | ||
Contact Material Copper Alloy | ||
Minimum Operating Temperature -40°C | ||
Termination Type Solder | ||
Row Pitch 2.54mm | ||
Contact Gender Male | ||
Maximum Operating Temperature 105°C | ||
Standards/Approvals cULus Recognised, VDE | ||
Voltage 160 V | ||
- COO (Country of Origin):
- PL
The Phoenix Contact PCB header is designed to seamlessly integrate into surface mount technology (SMT) processes, enhancing your circuit design with its compact and efficient layout. With a pitch of 2.54 mm and a robust construction, this component is ideal for applications where space is at a premium. Its gold-plated contacts ensure long-term stability and reliable performance, making it suitable for various electronic devices. Additionally, the vertical connection capability allows for multi-row arrangements, maximising component density on the PCB. Its exceptional electrical parameters and solid mechanical testing ensure it meets rigorous industry standards, proving essential for modern electronic assemblies.
Vertical connection facilitates optimal use of space
Gold-plated contacts maintain superior transfer quality
Designed for reliable operation in SMT processes
Offers excellent electrical insulation properties
Compact design suits tight spaces in electronic applications
Tested for durability and performance under extreme conditions
Composed of RoHS-compliant materials for environmental safety
