Phoenix Contact DMCV Series Straight Surface Mount PCB Header, 30 Contact(s), 2.54mm Pitch, 2 Row(s), Shrouded
- RS Stock No.:
- 557-614
- Mfr. Part No.:
- 1845302
- Brand:
- Phoenix Contact
Subtotal (1 pack of 330 units)*
£2,074.16
(exc. VAT)
£2,488.99
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 05 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Pack(s) | Per Pack | Per unit* |
---|---|---|
1 + | £2,074.16 | £6.285 |
*price indicative
- RS Stock No.:
- 557-614
- Mfr. Part No.:
- 1845302
- Brand:
- Phoenix Contact
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Phoenix Contact | |
Series | DMCV | |
Pitch | 2.54mm | |
Number of Contacts | 30 | |
Number of Rows | 2 | |
Body Orientation | Straight | |
Shrouded/Unshrouded | Shrouded | |
Mounting Type | Surface Mount | |
Select all | ||
---|---|---|
Brand Phoenix Contact | ||
Series DMCV | ||
Pitch 2.54mm | ||
Number of Contacts 30 | ||
Number of Rows 2 | ||
Body Orientation Straight | ||
Shrouded/Unshrouded Shrouded | ||
Mounting Type Surface Mount | ||
- COO (Country of Origin):
- PL
The Phoenix Contact PCB header is engineered to excel in high-performance electronic applications where space and reliability are paramount. This innovative component is designed for surface-mounted technology (SMT), enabling efficient integration into modern PCB layouts. With a compact design that supports vertical connections in multi-row configurations, it is ideal for space-constrained environments. Gold-plated contacts ensure long-term stability and excellent transfer quality, making it a trustworthy choice for demanding applications. The robust construction of this product is complemented by its compatibility with reflow soldering processes, ensuring seamless assembly in automated production lines. Durability is further enhanced by its wide temperature range, making it suitable for various operating conditions.
Optimised for surface mount technology to streamline production processes
Vertical connection design promotes efficient space usage on PCBs
Gold-plated contacts provide long-lasting stability and performance
Compact size enables integration in tight spaces without compromising functionality
Solder pins designed for reliable single-point connections
Moisture Sensitive Level of 1 ensures long-term reliability
Manufactured with RoHS-compliant materials for environmental responsibility
The component is well-suited for use in high-temperature applications
Vertical connection design promotes efficient space usage on PCBs
Gold-plated contacts provide long-lasting stability and performance
Compact size enables integration in tight spaces without compromising functionality
Solder pins designed for reliable single-point connections
Moisture Sensitive Level of 1 ensures long-term reliability
Manufactured with RoHS-compliant materials for environmental responsibility
The component is well-suited for use in high-temperature applications
