Phoenix Contact DMCV Series Vertical Surface PCB Header, 8 Contact(s), 2.54 mm Pitch, 2 Row(s), Shrouded
- RS Stock No.:
- 558-581
- Mfr. Part No.:
- 1845195
- Brand:
- Phoenix Contact
Subtotal (1 pack of 330 units)*
£602.17
(exc. VAT)
£722.60
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 27 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Pack(s) | Per Pack | Per unit* |
|---|---|---|
| 1 + | £602.17 | £1.825 |
*price indicative
- RS Stock No.:
- 558-581
- Mfr. Part No.:
- 1845195
- Brand:
- Phoenix Contact
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Phoenix Contact | |
| Product Type | PCB Header | |
| Series | DMCV | |
| Pitch | 2.54mm | |
| Current | 6A | |
| Number of Contacts | 8 | |
| Housing Material | Liquid Crystal Polymer | |
| Number of Rows | 2 | |
| Orientation | Vertical | |
| Shrouded/Unshrouded | Shrouded | |
| Connector System | COMBICON DFMC 0.5 | |
| Mount Type | Surface | |
| Contact Plating | Gold Plated | |
| Contact Material | Copper Alloy | |
| Termination Type | Solder | |
| Minimum Operating Temperature | -40°C | |
| Row Pitch | 2.54mm | |
| Maximum Operating Temperature | 105°C | |
| Contact Gender | Male | |
| Standards/Approvals | cULus Recognised, VDE | |
| Voltage | 160 V | |
| Select all | ||
|---|---|---|
Brand Phoenix Contact | ||
Product Type PCB Header | ||
Series DMCV | ||
Pitch 2.54mm | ||
Current 6A | ||
Number of Contacts 8 | ||
Housing Material Liquid Crystal Polymer | ||
Number of Rows 2 | ||
Orientation Vertical | ||
Shrouded/Unshrouded Shrouded | ||
Connector System COMBICON DFMC 0.5 | ||
Mount Type Surface | ||
Contact Plating Gold Plated | ||
Contact Material Copper Alloy | ||
Termination Type Solder | ||
Minimum Operating Temperature -40°C | ||
Row Pitch 2.54mm | ||
Maximum Operating Temperature 105°C | ||
Contact Gender Male | ||
Standards/Approvals cULus Recognised, VDE | ||
Voltage 160 V | ||
- COO (Country of Origin):
- PL
The Phoenix Contact PCB header is designed to provide reliable connections in a compact format, facilitating seamless integration into traditional and modern electronic circuits. With its gold-plated contacts, the product ensures long-lasting transfer quality, making it ideal for applications where durability and efficiency are paramount. The thoughtful design enables vertical connections, which aids in maximising space on the PCB, while the mounting method allows for straightforward SMD soldering. Crafted for versatility, this product caters to a wide array of electronic applications, cementing itself as a go-to solution for engineers and designers seeking quality and performance in every connection.
Gold-plated contacts preserve transfer quality over time
Suitable for integration into the SMT manufacturing process
Vertical connection capability allows multi-row PCB arrangements
Compact design fits well in space-constrained applications
Compliant with WEEE and RoHS directives for eco-friendly standards
Moisture Sensitive Level 1 ensures reliability during assembly
Tested for durability against insertion and withdrawal cycles
