Phoenix Contact DMC Series Straight Surface Mount PCB Header, 24 Contact(s), 2.54mm Pitch, 2 Row(s), Shrouded
- RS Stock No.:
- 557-608
- Mfr. Part No.:
- 1845124
- Brand:
- Phoenix Contact
Subtotal (1 pack of 300 units)*
£1,520.63
(exc. VAT)
£1,824.76
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 16 December 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Pack(s) | Per Pack | Per unit* |
---|---|---|
1 + | £1,520.63 | £5.069 |
*price indicative
- RS Stock No.:
- 557-608
- Mfr. Part No.:
- 1845124
- Brand:
- Phoenix Contact
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Phoenix Contact | |
Series | DMC | |
Pitch | 2.54mm | |
Number of Contacts | 24 | |
Number of Rows | 2 | |
Body Orientation | Straight | |
Shrouded/Unshrouded | Shrouded | |
Mounting Type | Surface Mount | |
Select all | ||
---|---|---|
Brand Phoenix Contact | ||
Series DMC | ||
Pitch 2.54mm | ||
Number of Contacts 24 | ||
Number of Rows 2 | ||
Body Orientation Straight | ||
Shrouded/Unshrouded Shrouded | ||
Mounting Type Surface Mount | ||
- COO (Country of Origin):
- PL
The Phoenix Contact PCB header is a meticulously designed connector that integrates seamlessly into the SMT assembly process. This component enhances connection reliability and efficiency with its gold-plated contacts, ensuring stable transfer quality over extended use. Perfectly suited for high-density applications, it offers a nominal current capacity of 6 A and a rated voltage of 160 V. The compact design features a pitch of 2.54 mm and is built for SMD soldering, making it an ideal choice for modern PCB layouts. With 12 positions and 24 connections, this header not only supports various configurations but also optimises space utilisation on circuit boards. Paired with a dual-row design, it provides robust performance across diverse electronic applications.
Gold-plated contacts enhance long-term connection stability
Designed for easy integration into automated assembly processes
Compact design promotes efficient use of space on PCBs
Dual-row layout maximises connection density within a small footprint
Moisture Sensitive Level MSL 1 ensures compatibility with standard soldering techniques
Integrated locking mechanism offers reliable stability during operation
Constructed from high-quality materials, achieving superior durability
Meets international compliance standards for environmental safety
Designed for easy integration into automated assembly processes
Compact design promotes efficient use of space on PCBs
Dual-row layout maximises connection density within a small footprint
Moisture Sensitive Level MSL 1 ensures compatibility with standard soldering techniques
Integrated locking mechanism offers reliable stability during operation
Constructed from high-quality materials, achieving superior durability
Meets international compliance standards for environmental safety
