Phoenix Contact MCDN Series Solder Mount PCB Header, 18 Contact(s), 3.5mm Pitch, 2 Row(s), Shrouded

View all PCB Headers
Currently unavailable
Sorry, we don't know when this will be back in stock.
RS Stock No.:
557-507
Mfr. Part No.:
1953787
Brand:
Phoenix Contact
Find similar products by selecting one or more attributes.
Select all

Brand

Phoenix Contact

Series

MCDN

Pitch

3.5mm

Number of Contacts

18

Number of Rows

2

Shrouded/Unshrouded

Shrouded

Mounting Type

Solder Mount

COO (Country of Origin):
DE
The Phoenix Contact PCB Header is part of the COMBICON Connectors S product line and is suitable for through-hole reflow. The mounting type supports both THR soldering and wave soldering. The pin layout is linear pinning, with contacts made from copper alloy. The surface is tin-plated, and the insulating material is LCP (Liquid Crystal Polymer).

Designed for integration into the SMT soldering process
Vertical connection enables multi row arrangement on the PCB
Maximum flexibility when it comes to device design which is one header for connectors with different connection technologies
Conductor connection on several levels enables higher contact density
