Phoenix Contact MSTB Series Angled Wave Soldering Mount PCB Header, 9 Contact(s), 5 mm Pitch, 1 Row(s), Shrouded
- RS Stock No.:
- 521-581
- Mfr. Part No.:
- 1769874
- Brand:
- Phoenix Contact
Subtotal (1 pack of 50 units)*
£209.49
(exc. VAT)
£251.39
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 20 February 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Pack(s) | Per Pack | Per unit* |
|---|---|---|
| 1 + | £209.49 | £4.19 |
*price indicative
- RS Stock No.:
- 521-581
- Mfr. Part No.:
- 1769874
- Brand:
- Phoenix Contact
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Phoenix Contact | |
| Product Type | PCB Header | |
| Series | MSTB | |
| Current | 12A | |
| Pitch | 5mm | |
| Number of Contacts | 9 | |
| Housing Material | Polyamide | |
| Number of Rows | 1 | |
| Orientation | Angled | |
| Shrouded/Unshrouded | Shrouded | |
| Mount Type | Wave Soldering Mount | |
| Connector System | COMBICON MSTB 2.5 | |
| Contact Material | Copper Alloy | |
| Contact Plating | Tin Plated | |
| Row Pitch | 5mm | |
| Termination Type | Solder | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | 100°C | |
| Tail Pin Length | 3.5mm | |
| Contact Gender | Male | |
| Standards/Approvals | CSA, cULus, IEC 61984, VDE | |
| Mating Pin Length | 3.5mm | |
| Voltage | 32 V | |
| Select all | ||
|---|---|---|
Brand Phoenix Contact | ||
Product Type PCB Header | ||
Series MSTB | ||
Current 12A | ||
Pitch 5mm | ||
Number of Contacts 9 | ||
Housing Material Polyamide | ||
Number of Rows 1 | ||
Orientation Angled | ||
Shrouded/Unshrouded Shrouded | ||
Mount Type Wave Soldering Mount | ||
Connector System COMBICON MSTB 2.5 | ||
Contact Material Copper Alloy | ||
Contact Plating Tin Plated | ||
Row Pitch 5mm | ||
Termination Type Solder | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature 100°C | ||
Tail Pin Length 3.5mm | ||
Contact Gender Male | ||
Standards/Approvals CSA, cULus, IEC 61984, VDE | ||
Mating Pin Length 3.5mm | ||
Voltage 32 V | ||
- COO (Country of Origin):
- PL
The Phoenix Contact PCB header is engineered to offer unparalleled versatility in device design, catering to various connector types. The robust SMSTBA 2.5/9-G line comes with precisely designed specifications that assure renowned mounting reliability and compatibility across global applications. With its distinct linear pinning layout and a pitch of 5 mm, it guarantees excellent performance for both professional and industrial settings. Its carefully crafted design involves a sturdy green housing made from PA insulating material, ensuring superior electrical insulation. This product is tailored with a wide array of technical capabilities, including a maximum current rating of 12 A and a rated voltage of 320 V, meeting essential operational requirements. Whether you are embarking on a new project or working on an existing setup, this component stands out as a prime choice to enhance connectivity.
Designed for maximum flexibility in device configurations
Compatible with a variety of connection technologies
Allows for multi-row arrangements on the PCB, optimising space
Crafted with WEEE/RoHS compliance, ensuring environmental safety
Provides reliable electrical properties for dependable performance
Incorporates a sturdy pin layout that supports effective wave soldering
Offered in a convenient packing unit of 50 pieces for ease of use
Manufactured in Poland, aligning with high-quality European standards
