Phoenix Contact MCDNV Series Straight Wave Soldering Mount PCB Header, 6 Contact(s), 3.5 mm Pitch, 2 Row(s), Shrouded
- RS Stock No.:
- 520-948
- Mfr. Part No.:
- 1952461
- Brand:
- Phoenix Contact
Subtotal (1 pack of 80 units)*
£241.93
(exc. VAT)
£290.32
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 21 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Pack(s) | Per Pack | Per unit* |
|---|---|---|
| 1 + | £241.93 | £3.024 |
*price indicative
- RS Stock No.:
- 520-948
- Mfr. Part No.:
- 1952461
- Brand:
- Phoenix Contact
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Phoenix Contact | |
| Series | MCDNV | |
| Product Type | PCB Header | |
| Current | 8A | |
| Pitch | 3.5mm | |
| Number of Contacts | 6 | |
| Housing Material | Liquid Crystal Polymer | |
| Number of Rows | 2 | |
| Orientation | Straight | |
| Shrouded/Unshrouded | Shrouded | |
| Mount Type | Wave Soldering Mount | |
| Connector System | COMBICON FMC 1 | |
| Contact Plating | Tin Plated | |
| Contact Material | Copper Alloy | |
| Row Pitch | 3.5mm | |
| Termination Type | Solder | |
| Minimum Operating Temperature | -40°C | |
| Contact Gender | Male | |
| Maximum Operating Temperature | 100°C | |
| Tail Pin Length | 2.6mm | |
| Standards/Approvals | cULus Recognised, VDE | |
| Mating Pin Length | 2.6mm | |
| Voltage | 160 V | |
| Select all | ||
|---|---|---|
Brand Phoenix Contact | ||
Series MCDNV | ||
Product Type PCB Header | ||
Current 8A | ||
Pitch 3.5mm | ||
Number of Contacts 6 | ||
Housing Material Liquid Crystal Polymer | ||
Number of Rows 2 | ||
Orientation Straight | ||
Shrouded/Unshrouded Shrouded | ||
Mount Type Wave Soldering Mount | ||
Connector System COMBICON FMC 1 | ||
Contact Plating Tin Plated | ||
Contact Material Copper Alloy | ||
Row Pitch 3.5mm | ||
Termination Type Solder | ||
Minimum Operating Temperature -40°C | ||
Contact Gender Male | ||
Maximum Operating Temperature 100°C | ||
Tail Pin Length 2.6mm | ||
Standards/Approvals cULus Recognised, VDE | ||
Mating Pin Length 2.6mm | ||
Voltage 160 V | ||
- COO (Country of Origin):
- DE
The Phoenix Contact PCB header is designed for optimal performance in electronic assemblies, providing reliable interconnections in a compact form factor. With a pitch of 3.5 mm and a vertical connection design, it allows for efficient multi-row arrangements on printed circuit boards. The integration into SMT soldering processes is seamless, facilitated by its THR soldering and wave soldering capabilities. The header boasts a robust construction with intuitive locking mechanisms to prevent accidental disconnection. This enhances the longevity and reliability of connections in demanding applications, making it ideal for a variety of industries.
Intuitive locking mechanism ensures secure connections
Designed for integration into various soldering processes
Compact dimensions facilitate space-saving designs
Constructed to withstand adverse environmental conditions
Lightweight design aids in minimizing overall assembly weight
Multi-row arrangement capability optimises PCB layout
Snap-in locking enhances ease of use during installation
RoHS-compliant materials reinforce environmental responsibility
