Phoenix Contact TVMSTB Series Right Angle PCB Header, 12 Contact(s), 5.08mm Pitch, 1 Row(s), Shrouded
- RS Stock No.:
- 520-815
- Mfr. Part No.:
- 1719040
- Brand:
- Phoenix Contact
Subtotal (1 pack of 50 units)*
£716.37
(exc. VAT)
£859.64
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 26 December 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Pack(s) | Per Pack | Per unit* |
---|---|---|
1 + | £716.37 | £14.327 |
*price indicative
- RS Stock No.:
- 520-815
- Mfr. Part No.:
- 1719040
- Brand:
- Phoenix Contact
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Phoenix Contact | |
Series | TVMSTB | |
Pitch | 5.08mm | |
Number of Contacts | 12 | |
Number of Rows | 1 | |
Body Orientation | Right Angle | |
Shrouded/Unshrouded | Shrouded | |
Select all | ||
---|---|---|
Brand Phoenix Contact | ||
Series TVMSTB | ||
Pitch 5.08mm | ||
Number of Contacts 12 | ||
Number of Rows 1 | ||
Body Orientation Right Angle | ||
Shrouded/Unshrouded Shrouded | ||
- COO (Country of Origin):
- SK
The Phoenix Contact PCB TWIN plug is designed for reliable and efficient connectivity in various electrical applications. Featuring advanced screw connection technology, it ensures a secure grip and easy assembly. The innovative design supports a nominal current of 12 A and a rated voltage of 400 V, making it ideal for demanding environments. Its compact form factor, with a pitch of 5.08 mm, allows for high-density layouts on PCBs, facilitating optimal space utilisation. Built with high-quality materials, this product guarantees durability and performance, while compliance with international standards assures users of its safety and reliability in operation. With multiple connection options, the PCB connector is a versatile solution for modern electronic applications and is perfect for projects requiring a robust connection.
No mounting flange allows for straightforward installation
Offers a high number of connections to enhance circuit capabilities
Features hot-dip tin-plated contact surfaces for improved conductivity
Built to withstand a wide range of ambient temperatures
Complies with WEEE/RoHS directives for environmental safety
Optimised for minimal contact resistance to enhance electrical performance
Offers a high number of connections to enhance circuit capabilities
Features hot-dip tin-plated contact surfaces for improved conductivity
Built to withstand a wide range of ambient temperatures
Complies with WEEE/RoHS directives for environmental safety
Optimised for minimal contact resistance to enhance electrical performance
