Phoenix Contact DMCV Series Vertical Through Hole PCB Header, 36 Contact(s), 3.5 mm Pitch, 2 Row(s), Shrouded

View all PCB Headers

Subtotal (1 pack of 50 units)*

£751.34

(exc. VAT)

£901.61

(inc. VAT)

Add to Basket
Select or type quantity
Temporarily out of stock
  • Shipping from 10 February 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Pack(s)
Per Pack
Per unit*
1 +£751.34£15.027

*price indicative

RS Stock No.:
497-154
Mfr. Part No.:
1787551
Brand:
Phoenix Contact
Find similar products by selecting one or more attributes.
Select all

Brand

Phoenix Contact

Product Type

PCB Header

Series

DMCV

Current

8A

Pitch

3.5mm

Number of Contacts

36

Housing Material

Liquid Crystal Polymer

Number of Rows

2

Orientation

Vertical

Shrouded/Unshrouded

Shrouded

Connector System

COMBICON DFMC 1

Mount Type

Through Hole

Contact Material

Copper Alloy

Contact Plating

Tin Plated

Minimum Operating Temperature

-40°C

Row Pitch

3.5mm

Termination Type

Solder

Tail Pin Length

2mm

Maximum Operating Temperature

100°C

Contact Gender

Male

Standards/Approvals

cULus Recognised, IEC 60068-2-70:1995-12, IEC 60068-2-82/JEDEC JESD 201, IEC 60512-1-1:2002-02, IEC 60512-1-2:2002-02, IEC 60512-13-5:2006-02, IEC 60512-15-1:2008-05, IEC 60512-3-1:2002-02, IEC 60512-5-1:2002-02, IEC 60664-1:2007-04, ISO 6988:1985-02, VDE report with production monitoring

Mating Pin Length

2mm

Voltage

160 V

COO (Country of Origin):
DE
The Phoenix Contact PCB header is designed for seamless integration into your SMT soldering processes, ensuring reliable connections in compact applications. Leveraging cutting-edge technology, it features a versatile pin layout that accommodates a multi-row arrangement, making it ideal for high-density boards. With a robust locking mechanism and superior mechanical stability provided by its screwable flange, this component guarantees durability and ease of use. The small form factor, combined with an intuitive release mechanism, allows for efficient installation and removal, optimising your assembly line workflow. Its impressive specifications make it suitable for various applications, maintaining performance under demanding conditions while being compliant with the latest environmental standards.

Designed for integration into automated soldering processes

Vertical alignment facilitates multi-row configurations

Screwable flange enhances overall stability

Snap-in locking mechanism ensures secure connections

Optimised for space-restricted applications

RoHS-compliant, supporting environmental sustainability

Suitable for reflow and wave soldering methods

High-quality tin-plated contact material for reliable conductivity

Offers excellent insulation resistance and creepage distances

Tested for durability, ensuring long-term reliability
