Phoenix Contact ICV Series Wave Soldering Mount PCB Header, 2 Contact(s), 5.08 mm Pitch, 1 Row(s), Shrouded

View all PCB Headers

Subtotal (1 pack of 50 units)*

£912.46

(exc. VAT)

£1,094.95

(inc. VAT)

Add to Basket
Select or type quantity
Temporarily out of stock
  • Shipping from 23 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Pack(s)
Per Pack
Per unit*
1 +£912.46£18.249

*price indicative

RS Stock No.:
497-135
Mfr. Part No.:
1786132
Brand:
Phoenix Contact
Find similar products by selecting one or more attributes.
Select all

Brand

Phoenix Contact

Product Type

PCB Header

Series

ICV

Current

12A

Pitch

5.08mm

Number of Contacts

2

Housing Material

Polyamide

Number of Rows

1

Shrouded/Unshrouded

Shrouded

Connector System

COMBICON MSTB 2.5

Mount Type

Wave Soldering Mount

Contact Plating

Tin

Contact Material

Copper Alloy

Termination Type

Solder

Minimum Operating Temperature

-40°C

Row Pitch

5.08mm

Contact Gender

Female

Maximum Operating Temperature

100°C

Tail Pin Length

3.6mm

Standards/Approvals

CSA, cULus, EN 60695-10-2, EN 60695-2-12, EN 60695-2-13, IEC 60068-2-70, IEC 60068-2-82, IEC 60512-1-1, IEC 60512-1-2, IEC 60512-13-5, IEC 60512-15-1, IEC 60512-3-1, IEC 60512-5-1, IEC 60664-1, IEC 61984, ISO 6988, JEDEC JESD 201, UL 94 V0, VDE

Mating Pin Length

3.6mm

Voltage

32 V

COO (Country of Origin):
DE
The Phoenix Contact PCB header is designed to offer exceptional connectivity solutions, complementing various connection technologies while enhancing device flexibility. With a nominal cross-section of 2.5 mm² and a robust current rating of 12 A, this product ensures reliable performance across a multitude of applications. Its innovative design features a compact pitch of 5.08 mm, facilitating seamless integration into any circuit configuration. Ideal for both standard and inverted connections, this PCB header simplifies installation and maintenance. Combined with industry-compliant materials, it promises durability and longevity, making it suitable for use in a wide range of environments.

Designed for easy PCB replacement using plug-in modules

Inverted header configuration provides touch-proof device outputs

Achieves maximum installation flexibility with a linear pin layout

Manufactured in compliance with WEEE/RoHS regulations

Ensures effective thermal management with high operational temperature ranges

Features a hot-dip tin-plated surface for enhanced durability

Guarantees reliable electrical performance with low contact resistance

Optimised for wave soldering, ensuring secure mounting options

Tamper-resistant design enhances reliability during operation

Meets stringent environmental and safety standards
