Phoenix Contact IPC Series Wave Soldering Mount PCB Header, 8 Contact(s), 10.16 mm Pitch, 1 Row(s), Shrouded
- RS Stock No.:
- 492-893
- Mfr. Part No.:
- 1969674
- Brand:
- Phoenix Contact
Subtotal (1 pack of 50 units)*
£1,602.44
(exc. VAT)
£1,922.93
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 26 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Pack(s) | Per Pack | Per unit* |
|---|---|---|
| 1 + | £1,602.44 | £32.049 |
*price indicative
- RS Stock No.:
- 492-893
- Mfr. Part No.:
- 1969674
- Brand:
- Phoenix Contact
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Phoenix Contact | |
| Product Type | PCB Header | |
| Series | IPC | |
| Pitch | 10.16mm | |
| Current | 76A | |
| Housing Material | Polyamide | |
| Number of Contacts | 8 | |
| Number of Rows | 1 | |
| Shrouded/Unshrouded | Shrouded | |
| Connector System | COMBICON PC 6 hybrid | |
| Mount Type | Wave Soldering Mount | |
| Contact Plating | Silver | |
| Contact Material | Copper Alloy | |
| Row Pitch | 10.16mm | |
| Minimum Operating Temperature | -40°C | |
| Contact Gender | Female | |
| Maximum Operating Temperature | 105°C | |
| Tail Pin Length | 4mm | |
| Standards/Approvals | cULus Recognised (E60425-20040202), EN 60695-10-2, EN 60695-2-12, EN 60695-2-13, IEC 60068-2-27, IEC 60068-2-6, IEC 60068-2-70, IEC 60512-1-1, IEC 60512-1-2, IEC 60512-13-5, IEC 60512-15-1, IEC 60512-3-1, IEC 60512-5-1, IEC 60512-9-1, IEC 60664-1, ISO 6988, UL 94 V0, VDE (40055586) | |
| Mating Pin Length | 4mm | |
| Voltage | 1000 V | |
| Select all | ||
|---|---|---|
Brand Phoenix Contact | ||
Product Type PCB Header | ||
Series IPC | ||
Pitch 10.16mm | ||
Current 76A | ||
Housing Material Polyamide | ||
Number of Contacts 8 | ||
Number of Rows 1 | ||
Shrouded/Unshrouded Shrouded | ||
Connector System COMBICON PC 6 hybrid | ||
Mount Type Wave Soldering Mount | ||
Contact Plating Silver | ||
Contact Material Copper Alloy | ||
Row Pitch 10.16mm | ||
Minimum Operating Temperature -40°C | ||
Contact Gender Female | ||
Maximum Operating Temperature 105°C | ||
Tail Pin Length 4mm | ||
Standards/Approvals cULus Recognised (E60425-20040202), EN 60695-10-2, EN 60695-2-12, EN 60695-2-13, IEC 60068-2-27, IEC 60068-2-6, IEC 60068-2-70, IEC 60512-1-1, IEC 60512-1-2, IEC 60512-13-5, IEC 60512-15-1, IEC 60512-3-1, IEC 60512-5-1, IEC 60512-9-1, IEC 60664-1, ISO 6988, UL 94 V0, VDE (40055586) | ||
Mating Pin Length 4mm | ||
Voltage 1000 V | ||
- COO (Country of Origin):
- PL
The Phoenix Contact PCB header from the IPC 16 series is designed to offer robust connectivity solutions tailored for various application needs. With its inverted header configuration, this connector is adept at ensuring touch-proof outputs, making it ideal for safe and reliable device connectivity. The product boasts a green housing, complemented by high-quality silver-plated contacts which enhance its electrical performance. Its versatile mounting options and well-established design principles provide users with flexibility in device design, ensuring optimal performance in diverse environments. Additionally, the product’s ability to withstand significant thermal and electrical stresses makes it an excellent choice for demanding applications, underlining its commitment to safety, durability, and innovation.
Inverted header configuration ensures safe and touch-proof device outputs
Green housing aesthetic provides easy identification in installations
High-quality silver-plated contacts enhance electrical conductivity and reliability
Designed for wave soldering, facilitating streamlined assembly processes
Screw locking mechanism guarantees secure connections under high load conditions
Integrated double steel spring adds an extra layer of stability and safety during operation
Comprehensive compatibility with COMBICON PC connectors for seamless integration
Robust construction is compliant with WEEE/RoHS directives, promoting environmental sustainability
