Phoenix Contact IPC Series Wave Soldering Mount PCB Header, 7 Contact(s), 10.16 mm Pitch, 1 Row(s), Shrouded
- RS Stock No.:
- 483-707
- Mfr. Part No.:
- 1969661
- Brand:
- Phoenix Contact
Subtotal (1 pack of 50 units)*
£1,409.11
(exc. VAT)
£1,690.93
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 26 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Pack(s) | Per Pack | Per unit* |
|---|---|---|
| 1 + | £1,409.11 | £28.182 |
*price indicative
- RS Stock No.:
- 483-707
- Mfr. Part No.:
- 1969661
- Brand:
- Phoenix Contact
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Phoenix Contact | |
| Series | IPC | |
| Product Type | PCB Header | |
| Pitch | 10.16mm | |
| Current | 76A | |
| Housing Material | Polyamide | |
| Number of Contacts | 7 | |
| Number of Rows | 1 | |
| Shrouded/Unshrouded | Shrouded | |
| Mount Type | Wave Soldering Mount | |
| Connector System | COMBICON PC 6 hybrid | |
| Contact Plating | Silver | |
| Contact Material | Copper Alloy | |
| Minimum Operating Temperature | -40°C | |
| Row Pitch | 10.16mm | |
| Termination Type | Solder | |
| Tail Pin Length | 4mm | |
| Contact Gender | Female | |
| Maximum Operating Temperature | 105°C | |
| Mating Pin Length | 4mm | |
| Standards/Approvals | cULus Recognised, VDE | |
| Voltage | 1000 V | |
| Select all | ||
|---|---|---|
Brand Phoenix Contact | ||
Series IPC | ||
Product Type PCB Header | ||
Pitch 10.16mm | ||
Current 76A | ||
Housing Material Polyamide | ||
Number of Contacts 7 | ||
Number of Rows 1 | ||
Shrouded/Unshrouded Shrouded | ||
Mount Type Wave Soldering Mount | ||
Connector System COMBICON PC 6 hybrid | ||
Contact Plating Silver | ||
Contact Material Copper Alloy | ||
Minimum Operating Temperature -40°C | ||
Row Pitch 10.16mm | ||
Termination Type Solder | ||
Tail Pin Length 4mm | ||
Contact Gender Female | ||
Maximum Operating Temperature 105°C | ||
Mating Pin Length 4mm | ||
Standards/Approvals cULus Recognised, VDE | ||
Voltage 1000 V | ||
- COO (Country of Origin):
- PL
The Phoenix Contact PCB header is designed for versatile usage, offering an effective solution for connecting devices across various applications. The inverted design allows for touch-proof outputs and PCB-to-PCB connections, ensuring safety and functionality. Engineered with high-quality materials, this product ensures reliable performance, with a robust construction that withstands environmental challenges. Its screw locking mechanism enhances mechanical stability, making it suitable for demanding installations. The connectors are compatible with various connection technologies, providing maximum flexibility in device design. Moreover, the integrated double steel spring adds an extra layer of safety, adapting to power fluctuations effortlessly, making this a prime choice for developers looking to optimise their devices.
Offers well-known mounting principles for global applicability
Compatible with multiple connection technologies for design flexibility
Inverted header configuration enhances safety in operational environments
Screwable flange provides superior mechanical stability
Double steel spring mitigates risks associated with temperature and power fluctuations
