3M 919 Series Straight Surface PCB Header, 8 Contact(s), 1.27 mm Pitch, 2 Row, Unshrouded

Subtotal (1 pack of 5700 units)*

£3,970.46

(exc. VAT)

£4,764.55

(inc. VAT)

Stocked by manufacturer

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Pack(s)	Per Pack	Per unit*
1 +	£3,970.46	£0.697

*price indicative

Specifications

Technical Reference

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	3M
	Series	919
	Product Type	PCB Header
	Current	1A
	Pitch	1.27mm
	Number of Contacts	8
	Number of Rows	2
	Orientation	Straight
	Shrouded/Unshrouded	Unshrouded
	Mount Type	Surface
	Contact Plating	Nickel
	Contact Material	Copper Alloy
	Row Pitch	1.27mm
	Minimum Operating Temperature	-40°C
	Maximum Operating Temperature	105°C
	Tail Pin Length	3.05mm
	Standards/Approvals	No
	Voltage	500V

	Select all
	Brand 3M
	Series 919
	Product Type PCB Header
	Current 1A
	Pitch 1.27mm
	Number of Contacts 8
	Number of Rows 2
	Orientation Straight
	Shrouded/Unshrouded Unshrouded
	Mount Type Surface
	Contact Plating Nickel
	Contact Material Copper Alloy
	Row Pitch 1.27mm
	Minimum Operating Temperature -40°C
	Maximum Operating Temperature 105°C
	Tail Pin Length 3.05mm
	Standards/Approvals No
	Voltage 500V

RoHS Status: Exempt

The 3M 8-Position Receptacle Connector with 0.050-Inch (1.27mm) Spacing, Surface-Mount Design, and Gold-Plated Contacts.

Contact Shape Square

Contact Material Copper Alloy
