WAGO 713 Series Angled Through Hole Header, 30 Contact(s), 3.5mm Pitch, 2 Row(s), Shrouded
- RS Stock No.:
- 224-632
- Mfr. Part No.:
- 713-1435
- Brand:
- WAGO
Subtotal (1 box of 20 units)*
£166.45
(exc. VAT)
£199.74
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 10 November 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Box(es) | Per Box | Per unit* |
---|---|---|
1 + | £166.45 | £8.323 |
*price indicative
- RS Stock No.:
- 224-632
- Mfr. Part No.:
- 713-1435
- Brand:
- WAGO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | WAGO | |
Series | 713 | |
Pitch | 3.5mm | |
Number of Contacts | 30 | |
Number of Rows | 2 | |
Body Orientation | Angled | |
Shrouded/Unshrouded | Shrouded | |
Mounting Type | Through Hole | |
Select all | ||
---|---|---|
Brand WAGO | ||
Series 713 | ||
Pitch 3.5mm | ||
Number of Contacts 30 | ||
Number of Rows 2 | ||
Body Orientation Angled | ||
Shrouded/Unshrouded Shrouded | ||
Mounting Type Through Hole | ||
- COO (Country of Origin):
- PL
The Wago THT Male Header offers a reliable and versatile connection solution designed for efficient PCB integration. With a dual row configuration and a pin spacing of 3.5 mm, this connector excels in minimising misconnection risks, ensuring a seamless user experience. Crafted for lead free reflow soldering, its housing is made from THT compatible insulation material, guaranteeing durability under varied conditions. The male header is designed to accommodate both horizontal and vertical mounting, catering to diverse installation needs.
Made from high quality insulation material suited for lead free techniques
Separated pin slots enhance safety and prevent damage during use
Strong ratings across multiple standards underline its reliability
Variable coding options allow for tailored solutions depending on project needs
Lightweight construction aids in simple integration within various projects
Separated pin slots enhance safety and prevent damage during use
Strong ratings across multiple standards underline its reliability
Variable coding options allow for tailored solutions depending on project needs
Lightweight construction aids in simple integration within various projects
