WAGO 721 Series Straight Through Hole Header, 14 Contact(s), 5 mm Pitch, 1 Row(s), Shrouded
- RS Stock No.:
- 222-541
- Mfr. Part No.:
- 721-174/001-000
- Brand:
- WAGO
Subtotal (1 box of 50 units)*
£179.78
(exc. VAT)
£215.74
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 22 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Box(es) | Per Box | Per unit* |
|---|---|---|
| 1 + | £179.78 | £3.596 |
*price indicative
- RS Stock No.:
- 222-541
- Mfr. Part No.:
- 721-174/001-000
- Brand:
- WAGO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | WAGO | |
| Product Type | Header | |
| Series | 721 | |
| Pitch | 5mm | |
| Current | 16A | |
| Number of Contacts | 14 | |
| Housing Material | Polyamide 66 | |
| Number of Rows | 1 | |
| Orientation | Straight | |
| Shrouded/Unshrouded | Shrouded | |
| Mount Type | Through Hole | |
| Connector System | MCS | |
| Contact Material | Electrolytic Copper | |
| Contact Plating | Tin | |
| Minimum Operating Temperature | 60°C | |
| Termination Type | Solder | |
| Row Pitch | 5mm | |
| Contact Gender | Male | |
| Tail Pin Length | 5mm | |
| Maximum Operating Temperature | 100°C | |
| Mating Pin Length | 5mm | |
| Standards/Approvals | RoHS | |
| Voltage | 25 V | |
| Select all | ||
|---|---|---|
Brand WAGO | ||
Product Type Header | ||
Series 721 | ||
Pitch 5mm | ||
Current 16A | ||
Number of Contacts 14 | ||
Housing Material Polyamide 66 | ||
Number of Rows 1 | ||
Orientation Straight | ||
Shrouded/Unshrouded Shrouded | ||
Mount Type Through Hole | ||
Connector System MCS | ||
Contact Material Electrolytic Copper | ||
Contact Plating Tin | ||
Minimum Operating Temperature 60°C | ||
Termination Type Solder | ||
Row Pitch 5mm | ||
Contact Gender Male | ||
Tail Pin Length 5mm | ||
Maximum Operating Temperature 100°C | ||
Mating Pin Length 5mm | ||
Standards/Approvals RoHS | ||
Voltage 25 V | ||
- COO (Country of Origin):
- PL
The Wago THT Male Header provides outstanding electrical performance, boasting a robust construction that guarantees safe and efficient operation. The connector's thoughtful design accommodates both horizontal and vertical PCB mounting, enabling flexibility for varied configurations. Furthermore, its special coding fingers ensure 100% protection against mismating, offering peace of mind during installation.
Flammability class V0 ensures superior fire safety
Processing temperature range supports versatile application environments
Environmental compliance guarantees adherence to industry standards
Designed for reliability in high demand railway applications
Gold plated contacts ensure excellent conductivity and durability
