WAGO 721 Series Straight Through Hole Header, 2 Contact(s), 5 mm Pitch, 1 Row, Shrouded
- RS Stock No.:
- 222-362
- Mfr. Part No.:
- 721-162/001-000
- Brand:
- WAGO
Subtotal (1 box of 200 units)*
£101.00
(exc. VAT)
£121.20
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 13 February 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Box(es) | Per Box | Per unit* |
|---|---|---|
| 1 + | £101.00 | £0.505 |
*price indicative
- RS Stock No.:
- 222-362
- Mfr. Part No.:
- 721-162/001-000
- Brand:
- WAGO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | WAGO | |
| Product Type | Header | |
| Series | 721 | |
| Pitch | 5mm | |
| Current | 16A | |
| Number of Contacts | 2 | |
| Housing Material | Polyamide 66 | |
| Number of Rows | 1 | |
| Orientation | Straight | |
| Shrouded/Unshrouded | Shrouded | |
| Mount Type | Through Hole | |
| Connector System | MCS | |
| Contact Plating | Tin | |
| Contact Material | Electrolytic Copper | |
| Row Pitch | 5mm | |
| Minimum Operating Temperature | 60°C | |
| Termination Type | Solder | |
| Contact Gender | Male | |
| Maximum Operating Temperature | 100°C | |
| Tail Pin Length | 5mm | |
| Standards/Approvals | RoHS | |
| Mating Pin Length | 5mm | |
| Voltage | 25 V | |
| Select all | ||
|---|---|---|
Brand WAGO | ||
Product Type Header | ||
Series 721 | ||
Pitch 5mm | ||
Current 16A | ||
Number of Contacts 2 | ||
Housing Material Polyamide 66 | ||
Number of Rows 1 | ||
Orientation Straight | ||
Shrouded/Unshrouded Shrouded | ||
Mount Type Through Hole | ||
Connector System MCS | ||
Contact Plating Tin | ||
Contact Material Electrolytic Copper | ||
Row Pitch 5mm | ||
Minimum Operating Temperature 60°C | ||
Termination Type Solder | ||
Contact Gender Male | ||
Maximum Operating Temperature 100°C | ||
Tail Pin Length 5mm | ||
Standards/Approvals RoHS | ||
Mating Pin Length 5mm | ||
Voltage 25 V | ||
- COO (Country of Origin):
- PL
The Wago THT Male Header is engineered to provide reliable and stable connections in electronic applications. Featuring a robust design with a pin spacing of 5 mm, this component ensures a hassle free assembly process, making it an essential addition for various PCB mounting scenarios. Its light grey finish not only adds a modern touch but also contributes to its versatility across different devices.
Includes variable coding and anti rotation protection for enhanced functionality
Constructed from high quality polyamide material for durability
Shock and vibration resistant making it suitable for demanding applications
Compliant with RoHS standards confirming environmental responsibility
