WAGO 721 Series Straight Through Hole Header, 2 Contact(s), 5 mm Pitch, 1 Row, Shrouded
- RS Stock No.:
- 222-346
- Mfr. Part No.:
- 721-132/001-000
- Brand:
- WAGO
Subtotal (1 box of 200 units)*
£96.96
(exc. VAT)
£116.35
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 16 February 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Box(es) | Per Box | Per unit* |
|---|---|---|
| 1 + | £96.96 | £0.485 |
*price indicative
- RS Stock No.:
- 222-346
- Mfr. Part No.:
- 721-132/001-000
- Brand:
- WAGO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | WAGO | |
| Series | 721 | |
| Product Type | Header | |
| Pitch | 5mm | |
| Current | 12A | |
| Number of Contacts | 2 | |
| Housing Material | Polyamide 66 | |
| Number of Rows | 1 | |
| Orientation | Straight | |
| Shrouded/Unshrouded | Shrouded | |
| Connector System | MCS | |
| Mount Type | Through Hole | |
| Contact Plating | Tin | |
| Contact Material | Electrolytic Copper | |
| Termination Type | Through-Hole Reflow (THR) Soldering | |
| Minimum Operating Temperature | 60°C | |
| Row Pitch | 5mm | |
| Maximum Operating Temperature | 100°C | |
| Contact Gender | Male | |
| Mating Pin Length | 5mm | |
| Standards/Approvals | RoHS | |
| Voltage | 32 V | |
| Select all | ||
|---|---|---|
Brand WAGO | ||
Series 721 | ||
Product Type Header | ||
Pitch 5mm | ||
Current 12A | ||
Number of Contacts 2 | ||
Housing Material Polyamide 66 | ||
Number of Rows 1 | ||
Orientation Straight | ||
Shrouded/Unshrouded Shrouded | ||
Connector System MCS | ||
Mount Type Through Hole | ||
Contact Plating Tin | ||
Contact Material Electrolytic Copper | ||
Termination Type Through-Hole Reflow (THR) Soldering | ||
Minimum Operating Temperature 60°C | ||
Row Pitch 5mm | ||
Maximum Operating Temperature 100°C | ||
Contact Gender Male | ||
Mating Pin Length 5mm | ||
Standards/Approvals RoHS | ||
Voltage 32 V | ||
- COO (Country of Origin):
- PL
The Wago THT Male Header connector is designed to enhance connectivity in various electronic applications. With its advanced soldering technology and robust design, it ensures reliable performance and a secure connection. Featuring a compact design, this connector easily fits into tight spaces on PCBs, making it ideal for modern electronics. Its light grey colour and durable materials ensure compatibility with a wide range of devices while maintaining an aesthetically pleasing look.
Constructed from quality materials to ensure durability
Supports configurations via straight or angled solder pins
Utilises coding fingers for reliable connection configurations
Complies with safety standards to meet diverse application needs
Light grey colour allows for easy colour matching in designs
Enhanced shock and vibration resistance for railway applications
