Keysight Technologies DSOX2004A Bench Oscilloscope, 70MHz, 4 Analogue Channels With RS Calibration

Keysight InfiniiVision X-Series mixed signal and digital storage oscilloscopes are affordable instruments incorporating advanced technologies which deliver exceptional capabilities. They offer the fastest waveform update rates in their class, for superior viewing of signal detail and capture of infrequent events. Engineers and technicians use oscilloscopes as their primary tools to test and debug designs in the computing, communications, semiconductor, aerospace/defence, automotive and wireless industries. Keysight InfiniiVision X-Series scopes are at work throughout these industries and are credited with being a revolutionary force in engineering education.

Update rates up to 50,000 waveforms/sec
Memory depth 100k points
Input Z 1-MΩ only (no 10:1 auto-detect)
Triggering: Edge; Pulse Width; Pattern; Video
High resolution display intensity gradation

For trouble-free reading of electrical signals, turn to this oscilloscope from Keysight Technologies. Its four analogue inputs can connect to a signal source, sending an easy-to-read waveform graph to its WVGA screen. This handy setup lets you breeze through measurements such as time, frequency and amplitude for comprehensive analysis. Thanks to its generous bandwidth of 70MHz, this device will accurately show high-frequency waveforms. This unit has a wide operating temperature range of 0°C to +50°C, so it'll beat the heat in harsh industrial settings.

• Rapid update rate of 200,000 waveforms per second for seeing your signal in greater detail
• Screen size of 8.5in for good visibility of results
• Optional CAN, LIN, I²C, SPI and RS232/UART protocols for performing serial analysis
• Maximum memory of 1Mpts for capturing more signal data

• Medical facilities
• Manufacturing industry
• Automotive maintenance
• Consumer technology servicing

The maximum rise time of this oscilloscope is just 5ns, so it will be up and running in no time flat.

Keysight InfiniiVision Series

Keysight InfiniiVision 2000 & 3000 X-Series offers the power of 4 instruments in 1: oscilloscope; logic analyzer; function generator; protocol analyzer. The models are fully upgradable (bandwidth, MSO, WaveGen, memory, measurement applications) to meet future requirements and protect investment.
