Pico Technology Oscilloscope Probe, AC/DC Current Type, 400Hz
- RS Stock No.:
- 898-6814
- Mfr. Part No.:
- TA019
- Brand:
- Pico Technology
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
- RS Stock No.:
- 898-6814
- Mfr. Part No.:
- TA019
- Brand:
- Pico Technology
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Pico Technology | |
| Probe Type | AC/DC Current | |
| Bandwidth | 400Hz | |
| Current | 600A | |
Select all | ||
|---|---|---|
Brand Pico Technology | ||
Probe Type AC/DC Current | ||
Bandwidth 400Hz | ||
Current 600A | ||
Pico 600 A AC/DC Current Probe TA019, BNC Connector
Pico TA019 current probe can measure AC and DC currents up to 60A.
Two current ranges controlled by selector switch
Low–battery indicator
Zero offset button
Output connectors BNC with screened lead
Screened lead for noise suppression
Accuracy: DC 0 to 600 A ± (2% reading +2 A); AC 0 to 300 A ± (2% reading +2 A); AC/DC 300 A to 500 A ± (3% reading +2 A); AC/DC 500 A to 600 A ± (6% reading +2 A)
AC frequency range 50Hz to 400Hz
Voltage output 1mV per 1A (0 to 600 mV AC & DC)
Max conductor size 30 mm
Operating environment 0 to +50 °C, 70% RH
Battery life 100 hours with carbon zinc
Battery type 9 V DC NEDA 1604, 6F22, 006P
Dimensions 178 x 70 x 33 mm
Low–battery indicator
Zero offset button
Output connectors BNC with screened lead
Screened lead for noise suppression
Accuracy: DC 0 to 600 A ± (2% reading +2 A); AC 0 to 300 A ± (2% reading +2 A); AC/DC 300 A to 500 A ± (3% reading +2 A); AC/DC 500 A to 600 A ± (6% reading +2 A)
AC frequency range 50Hz to 400Hz
Voltage output 1mV per 1A (0 to 600 mV AC & DC)
Max conductor size 30 mm
Operating environment 0 to +50 °C, 70% RH
Battery life 100 hours with carbon zinc
Battery type 9 V DC NEDA 1604, 6F22, 006P
Dimensions 178 x 70 x 33 mm
