RS PRO SMD Non Resettable Fuse 6A, 125V
- RS Stock No.:
- 182-3932
- Brand:
- RS PRO
Currently unavailable
We don't know if this item will be back in stock, RS intend to remove it from our range soon.
- RS Stock No.:
- 182-3932
- Brand:
- RS PRO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | RS PRO | |
Current Rating | 6A | |
Voltage Rating | 125V | |
Fuse Speed | T | |
Body Material | Ceramic Tube Non Transparent | |
Body Length | 6.1mm | |
Body Width | 2.6mm | |
Body Height | 2.6mm | |
Breaking Capacity at Maximum Voltage Rating | 50 A @ 125 V ac/dc | |
Minimum Operating Temperature | -55°C | |
Maximum Operating Temperature | +125°C | |
Dimensions | 6.1 x 2.6 x 2.6mm | |
Terminal Material | Brass | |
Select all | ||
---|---|---|
Brand RS PRO | ||
Current Rating 6A | ||
Voltage Rating 125V | ||
Fuse Speed T | ||
Body Material Ceramic Tube Non Transparent | ||
Body Length 6.1mm | ||
Body Width 2.6mm | ||
Body Height 2.6mm | ||
Breaking Capacity at Maximum Voltage Rating 50 A @ 125 V ac/dc | ||
Minimum Operating Temperature -55°C | ||
Maximum Operating Temperature +125°C | ||
Dimensions 6.1 x 2.6 x 2.6mm | ||
Terminal Material Brass | ||
- COO (Country of Origin):
- TW
RS PRO Slow Blow Surface Mount Fuse
The RS PRO slow blow square ceramic non-resettable surface mount fuse has a voltage rating of 125V and current rating of 6A. It has a square cap of 2.60mm ± 0.10mm and overall size of 6.10mm ± 0.20mm. It has a non-transparent ceramic tube body that does not allow breaking or deformation. The fuse is used in portable EV chargers, cooling fan systems, battery management systems, and notebook PCs.
Features and Benefits
• Operating temperature ranging between -55°C and 125°C
• Two gold-plated brass end caps for good conductivity
• Nominal resistance ranging between 0.0063ohms and 0.0117ohms
• Fuse speed marking: T
• Fuse element: copper alloy
• Two gold-plated brass end caps for good conductivity
• Nominal resistance ranging between 0.0063ohms and 0.0117ohms
• Fuse speed marking: T
• Fuse element: copper alloy
Applications
• Wireless base stations
• Telecommunication and networking equipment
• Industrial equipment
• Medical equipment
• Telecommunication and networking equipment
• Industrial equipment
• Medical equipment
Certifications
• ANSI/ESD S20.20:2014
• BS EN 61340-5-1:2007
• BS EN 61340-5-1:2007
