MOXA EDS-611-T Managed 11 Port Ethernet Switch
- RS Stock No.:
- 633-654
- Mfr. Part No.:
- EDS-611-T
- Brand:
- MOXA
Subtotal (1 unit)*
£2,261.52
(exc. VAT)
£2,713.82
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 22 September 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £2,261.52 |
*price indicative
- RS Stock No.:
- 633-654
- Mfr. Part No.:
- EDS-611-T
- Brand:
- MOXA
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | MOXA | |
| Product Type | Ethernet Switch | |
| Number of Ports | 11 | |
| Switch Type | Managed | |
| Model Number | EDS-611-T | |
| Number of RJ-45 Ports | 8 | |
| Number of SFP Ports | 3 | |
| Height | 151mm | |
| Width | 125mm | |
| Standards/Approvals | IEC 61000-4-6, IEC 61000-4-5, IEC 61000-4-4, IEC 61000-4-3, IEC 61000-4-2, IEC 60068-2-6, IEC 60068-2-27, GB, FCC Part 15B Class A, EN 62368-1, EN 61000-6-2/-6-4, EN 55032/35, EN 50121-4, DNV, CISPR 32, ATEX Class I Division 2, ABS, IEEE 802.1p, IEC 61000-4-8, IEEE 802.1s, IEEE 802.1q, IEEE 802.1D-2004, UL 508, Telcordia (Bellcore), NK, NEMA TS2, LR, IEEE 802.3x, IEEE 802.3u, IEEE 802.3ad, IEEE 802.3ab, IEEE 802.3, IEEE 802.1X, IEEE 802.1w | |
| Depth | 157.4mm | |
| Select all | ||
|---|---|---|
Brand MOXA | ||
Product Type Ethernet Switch | ||
Number of Ports 11 | ||
Switch Type Managed | ||
Model Number EDS-611-T | ||
Number of RJ-45 Ports 8 | ||
Number of SFP Ports 3 | ||
Height 151mm | ||
Width 125mm | ||
Standards/Approvals IEC 61000-4-6, IEC 61000-4-5, IEC 61000-4-4, IEC 61000-4-3, IEC 61000-4-2, IEC 60068-2-6, IEC 60068-2-27, GB, FCC Part 15B Class A, EN 62368-1, EN 61000-6-2/-6-4, EN 55032/35, EN 50121-4, DNV, CISPR 32, ATEX Class I Division 2, ABS, IEEE 802.1p, IEC 61000-4-8, IEEE 802.1s, IEEE 802.1q, IEEE 802.1D-2004, UL 508, Telcordia (Bellcore), NK, NEMA TS2, LR, IEEE 802.3x, IEEE 802.3u, IEEE 802.3ad, IEEE 802.3ab, IEEE 802.3, IEEE 802.1X, IEEE 802.1w | ||
Depth 157.4mm | ||
- COO (Country of Origin):
- TW
The Moxa Europe Compact modular managed Ethernet switches offer a flexible modular design that allows users to combine fiber and copper modules to build customized switch solutions for diverse automation networks. Supporting up to 3 Gigabit Ethernet ports and 8 Fast Ethernet ports, the switches enhance network reliability and availability with Turbo Ring and Turbo Chain technologies featuring recovery times under 20 ms, along with RSTP, STP, and MSTP. Designed for harsh industrial environments, models are available with an extended operating temperature range of -40 to 75°C. The EDS-611 Series also supports a wide range of intelligent and secure networking functions, including EtherNet/IP, Modbus TCP, LLDP, DHCP Option 82, SNMP Inform, QoS, IGMP snooping, VLAN, TACACS+, IEEE 802.1X, HTTPS, SSH, and SNMPv3.
RMON for proactive and efficient network monitoring
Bandwidth management to prevent unpredictable network status
Automatic warning by exception through email and relay output
Port mirroring for online debugging
