Eaton 12A PKZM 01 Motor Protection Circuit Breaker, 690V, 40 °C, -25 °C
- RS Stock No.:
- 272-7345
- Mfr. Part No.:
- 286088 PKZM01-12-G
- Brand:
- Eaton
Subtotal (1 unit)*
£115.92
(exc. VAT)
£139.10
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 03 June 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £115.92 |
*price indicative
- RS Stock No.:
- 272-7345
- Mfr. Part No.:
- 286088 PKZM01-12-G
- Brand:
- Eaton
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Eaton | |
| Product Type | Motor Protection Circuit Breaker | |
| Current Rating | 12A | |
| Motor Protection Component | Circuit Breaker | |
| Supply Voltage | 690V | |
| Motor Protection System | Motor Protective Circuit Breaker | |
| Series | PKZM 01 | |
| Sensing Type | Phase Failure Sensitive | |
| Overall Length | 158mm | |
| Overall Width | 117mm | |
| IP Rating | IP65 | |
| Overall Depth | 158mm | |
| Minimum Operating Temperature | -25°C | |
| Maximum Operating Temperature | 40°C | |
| Standards/Approvals | VDE IEC/EN 60947, CSA Std. C22.2 No. 14, VDE 0660, UL 508, IEC 60947-4-1 | |
| Number of Poles | 3 | |
| Select all | ||
|---|---|---|
Brand Eaton | ||
Product Type Motor Protection Circuit Breaker | ||
Current Rating 12A | ||
Motor Protection Component Circuit Breaker | ||
Supply Voltage 690V | ||
Motor Protection System Motor Protective Circuit Breaker | ||
Series PKZM 01 | ||
Sensing Type Phase Failure Sensitive | ||
Overall Length 158mm | ||
Overall Width 117mm | ||
IP Rating IP65 | ||
Overall Depth 158mm | ||
Minimum Operating Temperature -25°C | ||
Maximum Operating Temperature 40°C | ||
Standards/Approvals VDE IEC/EN 60947, CSA Std. C22.2 No. 14, VDE 0660, UL 508, IEC 60947-4-1 | ||
Number of Poles 3 | ||
- COO (Country of Origin):
- DE
The Eaton Moeller series PKZM01 motor protective circuit breaker that has phase failure sensitive and motor protection functions. It has operating frequency is 40 Operations per hour.
Pollution degree 3
screw terminal connection
