Amphenol Industrial, MS Cable MIL Spec Circular Connector Plug, Socket Contacts,Shell Size 6, Bayonet, MIL-DTL-5015
- RS Stock No.:
- 200-5398
- Mfr. Part No.:
- MS3106E14S-6P
- Brand:
- Amphenol Industrial
3 In stock - FREE next working day delivery available
Price Each
£45.97
(exc. VAT)
£55.16
(inc. VAT)
Units | Per unit |
---|---|
1 - 9 | £45.97 |
10 + | £42.34 |
- RS Stock No.:
- 200-5398
- Mfr. Part No.:
- MS3106E14S-6P
- Brand:
- Amphenol Industrial
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- GB
Product Details
The Amphenol MS-E connectors meet the latest performance requirements of MIL-DTL-5015. These connectors represent well-proven electrical capability at an acceptable cost for most equipment where durability is important. Class E connectors are recommended for conditions where vibration, moisture, pressure and/or temperature are extreme. Strain relief is supplied on most shell sizes.
Operating voltage to 3000 VAC (RMS) at sea level
305 contact arrangements from 1 to 104 circuits
Solder or crimp contacts, sizes 16-0 accepting 22-0 AWG
305 contact arrangements from 1 to 104 circuits
Solder or crimp contacts, sizes 16-0 accepting 22-0 AWG
Specifications
Attribute | Value |
---|---|
Gender | Male |
Contact Gender | Female |
Current Rating | 13A |
Voltage Rating | 250 V |
Shell Size | 6 |
Mounting Type | Cable |
Military Standard | MIL-DTL-5015 |
Mating Type | Bayonet |
Body Orientation | Straight |
Series | MS |
