C & K Lever Snap Action Micro Switch, Pc Pin Terminal, 100 mA @ 30 V dc, SP-CO
- RS Stock No.:
- 154-3591
- Mfr. Part No.:
- MS-118305-A
- Brand:
- C & K
Bulk discount available
Subtotal (1 pack of 10 units)*
£5.26
(exc. VAT)
£6.31
(inc. VAT)
FREE delivery for orders over £50.00
Last RS stock
- 250 left, ready to ship
- Plus 120 left, ready to ship from another location
- Final 670 unit(s) shipping from 09 October 2025
Units | Per unit | Per Pack* |
---|---|---|
10 - 10 | £0.526 | £5.26 |
20 - 30 | £0.495 | £4.95 |
40 - 90 | £0.482 | £4.82 |
100 - 190 | £0.47 | £4.70 |
200 + | £0.458 | £4.58 |
*price indicative
- RS Stock No.:
- 154-3591
- Mfr. Part No.:
- MS-118305-A
- Brand:
- C & K
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | C & K | |
Actuator Type | Lever | |
Terminal Type | Pc Pin | |
Contact Current Rating | 100 mA @ 30 V dc | |
Contact Configuration | SP-CO | |
Operating Force | 25 gf | |
Minimum Operating Temperature | -20°C | |
Maximum Operating Temperature | +70°C | |
Contact Material | Silver Plated | |
Case Material | PBT | |
Mechanical Life | 50000 cycles, 500000 cycles | |
Voltage Rating | 30V dc | |
Operating Temperature Range | -20 → +70°C | |
Select all | ||
---|---|---|
Brand C & K | ||
Actuator Type Lever | ||
Terminal Type Pc Pin | ||
Contact Current Rating 100 mA @ 30 V dc | ||
Contact Configuration SP-CO | ||
Operating Force 25 gf | ||
Minimum Operating Temperature -20°C | ||
Maximum Operating Temperature +70°C | ||
Contact Material Silver Plated | ||
Case Material PBT | ||
Mechanical Life 50000 cycles, 500000 cycles | ||
Voltage Rating 30V dc | ||
Operating Temperature Range -20 → +70°C | ||
- COO (Country of Origin):
- CN
C&K Micro Switch
The C&K pushbutton is a single pole double throw (SPDT) switch. It is also known as a snap action switch. It operates by using a spring-loaded lever to open and close a set of internal contacts inside the unit. It has a level type actuator. It requires 25gf operating force to energize the spring. The operating current rating is 100mA.
Features and Benefits
• Detect interlock and movement
• Long life up to 500,000 life cycles
• Operating temperature ranges between -40°C and 85°C
• PBT is used as a contact material with silver-plated terminals
• Through hole type mounting
• Voltage rating is 30VDC
• Long life up to 500,000 life cycles
• Operating temperature ranges between -40°C and 85°C
• PBT is used as a contact material with silver-plated terminals
• Through hole type mounting
• Voltage rating is 30VDC
Applications
• Audio visual equipment
• Automotive instrument
• Consumer electronics equipment
• Industrial meters
• Medical
• Automotive instrument
• Consumer electronics equipment
• Industrial meters
• Medical
