ABB, Protecta, XT1N Molded Case Circuit Breaker 3-Pole 32A, Breaking Capacity 36 kA, DIN Rail
- RS Stock No.:
- 831-9169
- Mfr. Part No.:
- 1SDA067411R1 XT1N 160 TMD 32-450 3p F F
- Brand:
- ABB
Subtotal (1 unit)*
£226.10
(exc. VAT)
£271.32
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- Plus 1 unit(s) shipping from 01 June 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £226.10 |
*price indicative
- RS Stock No.:
- 831-9169
- Mfr. Part No.:
- 1SDA067411R1 XT1N 160 TMD 32-450 3p F F
- Brand:
- ABB
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | ABB | |
| Product Type | Molded Case Circuit Breaker | |
| Range | Protecta | |
| Series | XT1N | |
| Number of Poles | 3 | |
| Current Rating | 32A | |
| Breaking Capacity | 36kA | |
| Mount Type | DIN Rail | |
| Rated AC Voltage | 690V ac | |
| Rated DC Voltage | 500V dc | |
| Height | 130mm | |
| Standards/Approvals | CE | |
| Width | 130mm | |
| Depth | 70mm | |
| Select all | ||
|---|---|---|
Brand ABB | ||
Product Type Molded Case Circuit Breaker | ||
Range Protecta | ||
Series XT1N | ||
Number of Poles 3 | ||
Current Rating 32A | ||
Breaking Capacity 36kA | ||
Mount Type DIN Rail | ||
Rated AC Voltage 690V ac | ||
Rated DC Voltage 500V dc | ||
Height 130mm | ||
Standards/Approvals CE | ||
Width 130mm | ||
Depth 70mm | ||
ABB MCCB, 8kV Rated Impulse Withstand Voltage, 800V Insulation Voltage Rating - XT1N Series - 1SDA067411R1
Quickly stop overloads and short circuits from damaging your equipment with this MCCB from ABB. Thanks to a 3-pole configuration, it disconnects all phases simultaneously when a fault strikes, so you can count on a speedy response to electrical problems. A thermo-magnetic release feature measures the circuit's current flow and trips the breaker when the temperature exceeds a predetermined threshold. This helps to prevent overheating in your systems. As it handles both AC and DC currents, this is a versatile option.
Features & Benefits
• Rating of 690V AC and 500V DC for use in high-voltage applications
• 8kV impulse withstand voltage rating means it handles power spikes
• Compact size of 130 (H) x 76.2 (W) x 70mm (D) to fit setups where space is at a premium
• Mechanical durability of 25,000 operating cycles for long-term performance
Applications
• Power distribution systems
• Manufacturing plants
• Telecommunication facilities
• Mining industry
Is this MCB energy-efficient?
Yes, it has a low power loss of 2.1W per pole, so it's an energy-efficient solution.
How much does the unit weigh?
It weighs just 1.077kg, so it's easy to handle during installation.
