Siemens, SENTRON MCCB 4P 100A, Breaking Capacity 55 kA, Fixed Mount
- RS Stock No.:
- 210-1699
- Mfr. Part No.:
- 3VA2010-5KP46-0AA0
- Brand:
- Siemens
Subtotal (1 unit)*
£1,045.47
(exc. VAT)
£1,254.56
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 27 November 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £1,045.47 |
*price indicative
Better World
Our Better World range features products that make it easy for you to make a greener product choice you can trust. Click here to find out more.
- RS Stock No.:
- 210-1699
- Mfr. Part No.:
- 3VA2010-5KP46-0AA0
- Brand:
- Siemens
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Siemens | |
| Range | SENTRON | |
| Series | 3VA2 | |
| Number of Poles | 4 | |
| Current Rating | 100A | |
| Breaking Capacity at Maximum Voltage Rating | 55 kA | |
| Rated AC Voltage | 690V | |
| Mounting Style | Fixed | |
| Better World Product | Yes | |
| Better World Claim | Concentrated or compact solution, Extended product life | |
| Circuit Breaker Type | MCCB | |
| Select all | ||
|---|---|---|
Brand Siemens | ||
Range SENTRON | ||
Series 3VA2 | ||
Number of Poles 4 | ||
Current Rating 100A | ||
Breaking Capacity at Maximum Voltage Rating 55 kA | ||
Rated AC Voltage 690V | ||
Mounting Style Fixed | ||
Better World Product Yes | ||
Better World Claim Concentrated or compact solution, Extended product life | ||
Circuit Breaker Type MCCB | ||
- COO (Country of Origin):
- CZ
The Siemens circuit breaker 3VA2 IEC frame 100 breaking capacity class M, line protection ETU850, LSI, molded-case circuit breaker with 8-series ETU for system protection. As an important element of SENTRON protective components for industrial and infrastructure applications, the 3VA molded-case circuit breakers from Siemens provide effective plant, starter and motor protection thanks to reliable shutdown in the event of an overload or short circuit. The 3VA molded-case circuit breakers set new standards in flexibility and the variety of modular accessories available. Standardized accessories for several sizes across all series of the 3VA1 and 3VA2 molded-case circuit breakers.
Key features of this version of the 3VA molded-case circuit breaker:
1. Compact design.
2. Available as version for plant protection and generator protection.
3. Available as 3-pole and 4-pole version.
4. Can be installed fixed, in plug-in design or as withdrawable version.
5. The series has a solid-state overcurrent trip unit.
6. Integrated display for measured values.
7. Integrated measuring function and optional communication connection via Modbus TCP, Modbus RTU, PROFINET and PROFIBUS.
8. Modular and easy-to-fit internal accessories with wide range of functions.
1. Compact design.
2. Available as version for plant protection and generator protection.
3. Available as 3-pole and 4-pole version.
4. Can be installed fixed, in plug-in design or as withdrawable version.
5. The series has a solid-state overcurrent trip unit.
6. Integrated display for measured values.
7. Integrated measuring function and optional communication connection via Modbus TCP, Modbus RTU, PROFINET and PROFIBUS.
8. Modular and easy-to-fit internal accessories with wide range of functions.
