Lovato ModuLo P1MB MCB, 2P, 63A Curve D, 230V AC, 80V DC, 10 kA Breaking Capacity
- RS Stock No.:
- 825-5781
- Mfr. Part No.:
- P1MB2PD63
- Brand:
- Lovato
Available to back order for despatch 29/05/2024
Added
Price Each
£44.47
(exc. VAT)
£53.36
(inc. VAT)
| Units | Per unit |
| 1 - 9 | £44.47 |
| 10 - 14 | £42.22 |
| 15 + | £40.82 |
Alternatives
This product is not currently available. Here are our alternative recommendations.
- RS Stock No.:
- 825-5781
- Mfr. Part No.:
- P1MB2PD63
- Brand:
- Lovato
Technical Reference
Legislation and Compliance
RoHS Status: Exempt
- COO (Country of Origin):
- IT
Product Details
P1MB MCBs 2P
Miniature Circuit Breakers up to 63A with positive indication by flag window
Ratings 1 to 63A
Tripping characteristics B, C and D
Rated insulation voltagei: 440V
Rated impulse withstand voltage: 4kV
Rated operating voltage: 230/400VAC
DIN rail mounting
Add-on blocks available
Tripping characteristics B, C and D
Rated insulation voltagei: 440V
Rated impulse withstand voltage: 4kV
Rated operating voltage: 230/400VAC
DIN rail mounting
Add-on blocks available
Lovato MCBs
Specifications
Attribute | Value |
|---|---|
| Number of Poles | 2P |
| Current Rating | 63A |
| Tripping Characteristics | Type D |
| Rated AC Voltage | 230 V, 400V |
| Rated DC Voltage | 80V |
| Breaking Capacity at Maximum Voltage Rating | 10 kA |
| Range | ModuLo |
| Series | P1MB |
| Circuit Breaker Type | MCB |
| Length | 86.5mm |
| Width | 36mm |
| Mounting Style | DIN Rail Mount |
| Depth | 80mm |
