Select all	Attribute	Value
	Brand	ABB
	Number of Poles	1
	Current Rating	40A
	Tripping Characteristics	Type C
	Rated AC Voltage	440V
	Rated DC Voltage	60V
	Breaking Capacity at Maximum Voltage Rating	6 kA
	Range	Compact Home
	Series	SH200
	Circuit Breaker Type	MCB
	Width	17.5mm
	Length	85mm
	Mounting Style	DIN Rail Mount
	Depth	69mm
	Model Number	SH201-C40
	Better World Claim	Designed for disassembly
	Better World Product	Yes
	Application	Residential
	Reset Actuator Type	Toggle Switch
	Terminal Contact Type	Screw Clamp

	Select all
	Brand ABB
	Number of Poles 1
	Current Rating 40A
	Tripping Characteristics Type C
	Rated AC Voltage 440V
	Rated DC Voltage 60V
	Breaking Capacity at Maximum Voltage Rating 6 kA
	Range Compact Home
	Series SH200
	Circuit Breaker Type MCB
	Width 17.5mm
	Length 85mm
	Mounting Style DIN Rail Mount
	Depth 69mm
	Model Number SH201-C40
	Better World Claim Designed for disassembly
	Better World Product Yes
	Application Residential
	Reset Actuator Type Toggle Switch
	Terminal Contact Type Screw Clamp

COO (Country of Origin):: DE

ABB SH200 Series MCB, 1 Pole, 40A Current Rating - 2CDS211001R0404 SH201-C40

This miniature circuit breaker is designed for efficiency in residential and commercial electrical systems. It provides protection against overloads and short circuits, ensuring safety across a range of applications. With strong performance characteristics and compliance with IEC/EN standards, it serves as a practical choice for professionals in the field.

Features & Benefits

• Delayed thermal and electromechanical tripping mechanisms provide trustworthy protection
• Complies with IEC/EN 60898-1 standards for safety
• Withstands a breaking capacity of 6kA for robust performance
• Rated for an AC voltage of 440V for diverse applications
• Designed for DIN Rail Mount, allowing for straightforward installation
• Recognised as a Better World Product, promoting sustainability through disassembly

Applications

• Utilised in residential power distribution systems
• Suitable for commercial electrical installations needing circuit protection
• Appropriate for automation environments to ensure machinery safety
• Employed in mechanical requiring consistent electrical performance

What is the installation process for this circuit breaker?

The device easily mounts on a standard DIN rail, making installation simple with minimal tools required.

Can it handle both AC and DC voltages?

Yes, it is rated for AC voltages up to 440V and DC voltages of 60V.

What maintenance is required for optimal performance?

Routine checks for functionality and connections should be carried out to ensure consistent performance over time.

How does it perform in high-temperature environments?

It operates effectively in ambient temperatures ranging from -25°C to +55°C.

Can this be used in conjunction with other protection devices?

Yes, it can be integrated with additional protective components to enhance system safety and performance.

Standards

BS EN 60898

ABB Compact Home

ABB Compact Home SH200 MCB, 1P, 40A Curve C, 440V AC, 60V DC, 6 kA Breaking Capacity
