ABB System Pro M Compact S200M MCB, 1P, 32A Curve B, 253V AC, 72V DC, 10 kA Breaking Capacity
- RS Stock No.:
- 535-6027
- Mfr. Part No.:
- 2CDS271001R0325 S201M-B32
- Brand:
- ABB
Subtotal (1 unit)*
£18.34
(exc. VAT)
£22.01
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 14 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 + | £18.34 |
*price indicative
- RS Stock No.:
- 535-6027
- Mfr. Part No.:
- 2CDS271001R0325 S201M-B32
- Brand:
- ABB
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | ABB | |
Number of Poles | 1 | |
Current Rating | 32A | |
Tripping Characteristics | Type B | |
Rated AC Voltage | 253V | |
Rated DC Voltage | 72V | |
Breaking Capacity at Maximum Voltage Rating | 10 kA | |
Range | System Pro M Compact | |
Series | S200M | |
Circuit Breaker Type | MCB | |
Width | 17.5mm | |
Length | 88mm | |
Mounting Style | DIN Rail Mount | |
Depth | 76mm | |
Model Number | S201M-B32 | |
Select all | ||
---|---|---|
Brand ABB | ||
Number of Poles 1 | ||
Current Rating 32A | ||
Tripping Characteristics Type B | ||
Rated AC Voltage 253V | ||
Rated DC Voltage 72V | ||
Breaking Capacity at Maximum Voltage Rating 10 kA | ||
Range System Pro M Compact | ||
Series S200M | ||
Circuit Breaker Type MCB | ||
Width 17.5mm | ||
Length 88mm | ||
Mounting Style DIN Rail Mount | ||
Depth 76mm | ||
Model Number S201M-B32 | ||
RoHS Status: Exempt
- COO (Country of Origin):
- DE
ABB S200M Series MCB, 32A, 10kA Breaking Capacity (at Maximum Voltage Rating) - 2CDS271001R0325 S201M-B32
This miniature circuit breaker (MCB) is essential for the protection of electrical circuits in commercial and industrial settings. It combines high performance with dependable operation, providing crucial safeguarding against overloads and short circuits. The MCB functions effectively across various voltages, making it significant for various application systems.
Features & Benefits
• Offers short circuit protection via electromechanical mechanisms
• Provides overload safety through thermal tripping functionality
• Designed for DIN rail mounting to optimise installation space
• Achieves a breaking capacity of up to 10kA at maximum voltage
• Complies with international safety standards
• Compact design enhances usability in confined spaces
• Provides overload safety through thermal tripping functionality
• Designed for DIN rail mounting to optimise installation space
• Achieves a breaking capacity of up to 10kA at maximum voltage
• Complies with international safety standards
• Compact design enhances usability in confined spaces
Applications
• Used in commercial infrastructure for circuit safety management
• Suitable for industrial machinery that needs overload and short circuit protection
• Ideal for integration in various automation systems
• Applied within electrical distribution boards for dependable circuit protection
• Commonly found in machine control systems to prevent damage
• Suitable for industrial machinery that needs overload and short circuit protection
• Ideal for integration in various automation systems
• Applied within electrical distribution boards for dependable circuit protection
• Commonly found in machine control systems to prevent damage
What is the maximum operational voltage of this device?
The device can operate at a maximum voltage of 253V AC and 72V DC, ensuring compatibility with standard electrical systems.
How does the thermal tripping mechanism function?
The thermal tripping mechanism activates when the device detects extended overload conditions, thus preventing potential damage to electrical circuits.
Is this suitable for outdoor installations?
The product is intended for indoor use and adheres to specified environmental conditions
outdoor applications may necessitate additional enclosures.
Can this be integrated with other circuit protection devices?
Yes, it is compatible with several other protection devices, allowing for a comprehensive safety system in electrical installations.
What maintenance does this product require?
Routine inspections should be conducted to ensure functionality, and regular tests of the tripping mechanism are advisable for reliability.
Standards
BS EN 60898
ABB System Pro M Single & Double Pole MCB's
Note
The Classic & System pro M product cannot be intermixed and do not share common accessories. System pro M products can only be fitted to new style Protecta distribution boards,see typically stock no. 539-1553.
