Schneider Electric MasterPact NW Masterpact NW Miniature Circuit Breaker, 4-Pole, 2 kA, Type B, 690 V ac AC, 65 kA
- RS Stock No.:
- 247-1894
- Mfr. Part No.:
- 48294
- Brand:
- Schneider Electric
Subtotal (1 unit)*
£11,479.61
(exc. VAT)
£13,775.53
(inc. VAT)
Add 1 unit to get free delivery
Temporarily out of stock
- Shipping from 08 April 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £11,479.61 |
*price indicative
- RS Stock No.:
- 247-1894
- Mfr. Part No.:
- 48294
- Brand:
- Schneider Electric
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Schneider Electric | |
| Number of Poles | 4 | |
| Product Type | Miniature Circuit Breaker | |
| Current Rating | 2 kA | |
| Tripping Characteristics | Type B | |
| Rated AC Voltage | 690 V ac | |
| Mount Type | DIN Rail | |
| Breaking Capacity | 65kA | |
| Range | MasterPact NW | |
| Series | Masterpact NW | |
| Terminal Type | Screw | |
| IP Rating | IP30 | |
| Width | 556 mm | |
| Depth | 394.5mm | |
| Height | 439mm | |
| Standards/Approvals | RoHS, REACH | |
| Reset Actuator Type | Push Button | |
| Select all | ||
|---|---|---|
Brand Schneider Electric | ||
Number of Poles 4 | ||
Product Type Miniature Circuit Breaker | ||
Current Rating 2 kA | ||
Tripping Characteristics Type B | ||
Rated AC Voltage 690 V ac | ||
Mount Type DIN Rail | ||
Breaking Capacity 65kA | ||
Range MasterPact NW | ||
Series Masterpact NW | ||
Terminal Type Screw | ||
IP Rating IP30 | ||
Width 556 mm | ||
Depth 394.5mm | ||
Height 439mm | ||
Standards/Approvals RoHS, REACH | ||
Reset Actuator Type Push Button | ||
- COO (Country of Origin):
- NL
The Schneider Electric Masterpact NW series circuit breaker has 4 poles and it is controlled via push-button. It has current rating of 2000 A.
Ambient air temperature for operation from -25 to 70 °C
Network frequency 50/60 Hz
