ABB SN201 Miniature Circuit Breaker, 1-Pole, 32 A, Type C, 400 V AC, 6 kA Breaking Capacity
- RS Stock No.:
- 237-1426
- Mfr. Part No.:
- 2CSS255101R0324
- Brand:
- ABB
Subtotal (1 unit)*
£33.49
(exc. VAT)
£40.19
(inc. VAT)
Add 2 units to get free delivery
Temporarily out of stock
- Shipping from 03 April 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £33.49 |
*price indicative
- RS Stock No.:
- 237-1426
- Mfr. Part No.:
- 2CSS255101R0324
- Brand:
- ABB
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | ABB | |
| Number of Poles | 1 | |
| Product Type | Miniature Circuit Breaker | |
| Current Rating | 32 A | |
| Tripping Characteristics | Type C | |
| Rated AC Voltage | 400 V | |
| Mount Type | DIN Rail | |
| Breaking Capacity | 6kA | |
| Series | SN201 | |
| Terminal Type | Cage Terminal | |
| IP Rating | IP40, IP20 | |
| Height | 85mm | |
| Standards/Approvals | IEC/EN 60898-1 | |
| Width | 18 mm | |
| Depth | 69mm | |
| Reset Actuator Type | Toggle | |
| Select all | ||
|---|---|---|
Brand ABB | ||
Number of Poles 1 | ||
Product Type Miniature Circuit Breaker | ||
Current Rating 32 A | ||
Tripping Characteristics Type C | ||
Rated AC Voltage 400 V | ||
Mount Type DIN Rail | ||
Breaking Capacity 6kA | ||
Series SN201 | ||
Terminal Type Cage Terminal | ||
IP Rating IP40, IP20 | ||
Height 85mm | ||
Standards/Approvals IEC/EN 60898-1 | ||
Width 18 mm | ||
Depth 69mm | ||
Reset Actuator Type Toggle | ||
- COO (Country of Origin):
- IT
The ABB SN201 series miniature circuit breaker is a 1P+N single-module device for the protection of circuits against overload and short circuit. It is suitable for the application in final distribution and protection of long cable lengths in TN and IT systems. Rated current is 32A.
Degree of Protection : Housing IP40
Terminals IP20
Tripping Characteristic: C
