Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	ABB
	Number of Poles	4
	Current Rating	4A
	Tripping Characteristics	Type C
	Rated AC Voltage	440V
	Rated DC Voltage	125V
	Breaking Capacity at Maximum Voltage Rating	25 kA
	Range	System Pro M Compact
	Series	S200M
	Circuit Breaker Type	MCB
	Width	70mm
	Length	88mm
	Mounting Style	DIN Rail Mount
	Depth	69mm
	Model Number	S204M-C4
	Better World Product	Yes
	Better World Claim	Designed for disassembly
	Application	Commercial, Residential
	Terminal Contact Type	Screw
	Reset Actuator Type	Toggle Switch

	Select all
	Brand ABB
	Number of Poles 4
	Current Rating 4A
	Tripping Characteristics Type C
	Rated AC Voltage 440V
	Rated DC Voltage 125V
	Breaking Capacity at Maximum Voltage Rating 25 kA
	Range System Pro M Compact
	Series S200M
	Circuit Breaker Type MCB
	Width 70mm
	Length 88mm
	Mounting Style DIN Rail Mount
	Depth 69mm
	Model Number S204M-C4
	Better World Product Yes
	Better World Claim Designed for disassembly
	Application Commercial, Residential
	Terminal Contact Type Screw
	Reset Actuator Type Toggle Switch

COO (Country of Origin):: DE

ABB S200M Series MCB, 4 Poles, 4A Current Rating - 2CDS274001R0044 S204M C 4A - 15 KA

This miniature circuit breaker is essential for protecting electrical systems across various environments. It focuses on performance and efficiency, guarding against overloads and short circuits. This product is well-suited for residential, commercial, and industrial applications, ensuring the safety and functionality of connected devices.

Features & Benefits

• Provides overload protection with a delayed thermal tripping mechanism
• Offers short circuit protection through electromechanical operation
• Easily mounts on standard DIN rail systems
• Energy-efficient design reduces power loss during operation
• 4A current rating accommodates diverse applications
• Compact design optimises space in electrical panels

Applications

• Used in automation and control panels for machinery
• Ideal for residential fuse boxes with limited space
• Employed in commercial electrical systems for enhanced protection
• Suitable for industrial control

How do I install it on a DIN rail?

Simply snap the device onto the DIN rail by aligning it with the grooves and pushing down until it is secured.

What is the maximum operational voltage it can handle?

It can operate at a maximum of 440V AC, making it compatible with various electrical systems.

Can it be used in outdoor installations?

It is advised for indoor use unless properly enclosed to protect against environmental factors.

What maintenance is required to ensure effective operation?

Regular inspections for secure mounting and visible damage are recommended to maintain functionality.

Is it compatible with all types of cables?

It accommodates a wide range of cable types, providing versatile connections for different installations.

ABB System Pro M Compact S200M MCB, 4P, 4A Curve C, 440V AC, 125V DC, 25 kA Breaking Capacity
