ABB System Pro M Compact S200 Miniature Circuit Breaker, 1-Pole, 20A, Type K, 253V AC, 6 kA Breaking Capacity

RS Stock No.:: 225-6000
Mfr. Part No.:: 2CDS251103R0487
Brand:: ABB

ABB System Pro M Compact S200 Miniature Circuit Breaker, 1-Pole, 20A, Type K, 253V AC, 6 kA Breaking Capacity

View all MCBs

Subtotal (1 unit)*

£65.51

(exc. VAT)

£78.61

(inc. VAT)

Stock information currently inaccessible - Please check back later

Units	Per unit
1 +	£65.51

*price indicative

Better World

Our Better World range features products that make it easy for you to make a greener product choice you can trust. Click here to find out more.

RS Stock No.:: 225-6000
Mfr. Part No.:: 2CDS251103R0487
Brand:: ABB

Specifications

Technical Reference

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	ABB
	Product Type	Miniature Circuit Breaker
	Number of Poles	1
	Current Rating	20A
	Tripping Characteristics	Type K
	Rated AC Voltage	253V
	Mount Type	DIN Rail
	Breaking Capacity	6kA
	Range	System Pro M Compact
	Series	S200
	Terminal Type	Screw
	IP Rating	IP20, IP40
	Standards/Approvals	IEC/EN 60898-1, IEC/EN 60947-2
	Height	88mm
	Depth	69mm
	Width	35mm
	Better World Product	Yes
	Better World Claim	Designed for Disassembly
	Tripping Mechanism	Thermal
	Reset Actuator Type	Toggle Switch

	Select all
	Brand ABB
	Product Type Miniature Circuit Breaker
	Number of Poles 1
	Current Rating 20A
	Tripping Characteristics Type K
	Rated AC Voltage 253V
	Mount Type DIN Rail
	Breaking Capacity 6kA
	Range System Pro M Compact
	Series S200
	Terminal Type Screw
	IP Rating IP20, IP40
	Standards/Approvals IEC/EN 60898-1, IEC/EN 60947-2
	Height 88mm
	Depth 69mm
	Width 35mm
	Better World Product Yes
	Better World Claim Designed for Disassembly
	Tripping Mechanism Thermal
	Reset Actuator Type Toggle Switch

ABB S200 Series MCB, 20A Current Rating , 1 Pole - 2CDS251103R0487

This miniature circuit breaker (MCB) is designed to provide reliable overload protection in commercial and industrial applications. Featuring a type K tripping mechanism, it effectively safeguards against both overloads and short circuits. With a current rating of 20 A and a Compact design suitable for DIN rail mounting, this device fits seamlessly into various electrical systems, ensuring safety and efficiency.

Features & Benefits

• Current limiting design enhances system protection
• Thermal tripping mechanism provides reliable overload safety
• Screw Terminal connections ensure secure wire fittings
• Compatible with auxiliary contacts for expanded functionality
• Designed for easy disassembly for recycling purposes
• Complies with international standards for quality assurance

Applications

• Used for overload protection in commercial installations
• Ideal for integration within industrial electrical systems
• Applicable in automated control panels for machinery
• Suitable for installations demanding robust circuit protection

How does the thermal tripping mechanism work for this device?

The thermal tripping mechanism operates by sensing prolonged overload conditions. When the temperature rises due to excess current, the mechanism trips, disconnecting the load to prevent damage.

What type of auxiliary contacts can be used with this MCB?

A variety of bottom-fitting auxiliary contacts are available, enabling users to enhance functionality and monitoring capabilities within their electrical system while saving space.

What is the significance of its compliance with IEC/EN standards?

Compliance with IEC/EN standards ensures the product meets regulatory requirements for safety, performance, and reliability, making it suitable for both residential and commercial applications.
