ABB System Pro M Compact S200 Miniature Circuit Breaker, 1-Pole, 16A, Type B, 253V AC, 6 kA Breaking Capacity

RS Stock No.:: 225-5999
Mfr. Part No.:: 2CDS251103R0165
Brand:: ABB

ABB System Pro M Compact S200 Miniature Circuit Breaker, 1-Pole, 16A, Type B, 253V AC, 6 kA Breaking Capacity

View all MCBs

Subtotal (1 unit)*

£57.36

(exc. VAT)

£68.83

(inc. VAT)

Stock information currently inaccessible - Please check back later

Units	Per unit
1 +	£57.36

*price indicative

Better World

Our Better World range features products that make it easy for you to make a greener product choice you can trust. Click here to find out more.

RS Stock No.:: 225-5999
Mfr. Part No.:: 2CDS251103R0165
Brand:: ABB

Specifications

Technical Reference

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	ABB
	Number of Poles	1
	Product Type	Miniature Circuit Breaker
	Current Rating	16A
	Tripping Characteristics	Type B
	Rated AC Voltage	253V
	Breaking Capacity	6kA
	Mount Type	DIN Rail
	Range	System Pro M Compact
	Series	S200
	Terminal Type	Screw
	IP Rating	IP20, IP40
	Width	35mm
	Depth	69mm
	Standards/Approvals	IEC/EN 60947-2, IEC/EN 60898-1
	Height	88mm
	Better World Product	Yes
	Better World Claim	Designed for Disassembly
	Reset Actuator Type	Toggle Switch
	Tripping Mechanism	Thermal

	Select all
	Brand ABB
	Number of Poles 1
	Product Type Miniature Circuit Breaker
	Current Rating 16A
	Tripping Characteristics Type B
	Rated AC Voltage 253V
	Breaking Capacity 6kA
	Mount Type DIN Rail
	Range System Pro M Compact
	Series S200
	Terminal Type Screw
	IP Rating IP20, IP40
	Width 35mm
	Depth 69mm
	Standards/Approvals IEC/EN 60947-2, IEC/EN 60898-1
	Height 88mm
	Better World Product Yes
	Better World Claim Designed for Disassembly
	Reset Actuator Type Toggle Switch
	Tripping Mechanism Thermal

COO (Country of Origin):: DE

ABB S200 Series MCB, 16A Current Rating , 1 Pole - 2CDS251103R0165

This miniature circuit breaker (MCB) is a single-pole, 16 A device designed for effective electrical protection in both commercial and industrial applications. Measuring 35 mm in width and 69 mm in length, this DIN rail-mounted circuit breaker features a robust design aligned with the System Pro M Compact range. It is engineered with Advanced tripping mechanisms, offering reliable performance under various operational conditions.

Features & Benefits

• Incorporates thermal tripping for enhanced overload protection
• Delivers effective short circuit protection via an electromechanical mechanism
• Compact design optimises space on DIN rail installations
• Complies with IEC and EN 60898-1 and UL 1077 standards, ensuring reliability
• Offers easy reset with a user friendly toggle switch actuator
• Equipped with screw Terminal contacts for secure connections

Applications

• Utilised in commercial settings for safety and compliance
• Ideal for industrial environments requiring dependable circuit management
• Suitable for control panels and distribution boards
• Effective protection in residential electrical installations

What type of current rating is supported by this device?

It supports a rated current of 16 A, suitable for various electrical applications.

How does the tripping mechanism operate for overload situations?

The device features a delayed thermal tripping mechanism that disconnects the circuit during overload conditions, protecting against potential hazards.

What mounting options are available for installation?

It is designed for DIN rail mounting, facilitating a secure and straightforward installation process within control panels.

Can this product be used in environments with extreme temperatures?

Operational limits range from -25°C to +55°C, making it suitable for diverse environmental conditions.

What materials are used in the construction of this product?

The housing is MADE from insulating materials to provide durability and safety during operation.
