Hager Hager NSN Circuit Breaker, 4P, 50A Curve D, 415V AC, 15 kA Breaking Capacity

View all MCBs

Subtotal (1 unit)*

£432.92

(exc. VAT)

£519.50

(inc. VAT)

Add to Basket
Select or type quantity
Temporarily out of stock
  • Shipping from 11 November 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
1 +£432.92

*price indicative

RS Stock No.:
599-728
Mfr. Part No.:
NSN450
Brand:
Hager
Find similar products by selecting one or more attributes.
Select all

Brand

Hager

Number of Poles

4

Current Rating

50A

Tripping Characteristics

Type D

Rated AC Voltage

415V

Breaking Capacity at Maximum Voltage Rating

15 kA

Range

Hager

Series

NSN

COO (Country of Origin):
PL
The Hager Miniature circuit breakers protect and control the circuits against overloads and short circuits. They also allow to isolate circuits. The circuit breaker is a four pole (4P) electrical protection device designed for four-phase circuits, offering protection against overloads and short circuits. It has a 15kA breaking capacity, meaning it can safely interrupt fault currents up to 15,000 amps without being damaged. The D-50A rating indicates that the breaker trips when the current exceeds 50 amps, with the D curve providing protection for circuits with high inrush currents, such as those used by large motors, industrial equipment, or transformers.

IEC 60947-2 standard
RoHS compliant
Top removability for modular devices
Bottom removability for modular devices
Suitable for flush mounting
