Eaton xPole PXL, S200 MCB, 2P, 10A Curve C, 400V AC, 48V DC, 10 kA Breaking Capacity

View all MCBs

Subtotal (1 unit)*

£47.69

(exc. VAT)

£57.23

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • 5 unit(s) ready to ship from another location
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
1 +£47.69

*price indicative

RS Stock No.:
490-084
Mfr. Part No.:
236285 PXL-C10/2
Brand:
Eaton
Find similar products by selecting one or more attributes.
Select all

Brand

Eaton

Number of Poles

2

Current Rating

10A

Tripping Characteristics

Type C

Rated AC Voltage

400V

Rated DC Voltage

48V

Breaking Capacity at Maximum Voltage Rating

10 kA

Range

xPole

Series

PXL, S200

Circuit Breaker Type

MCB

Width

80mm

Length

35mm

Mounting Style

DIN Rail Mount

Depth

60mm

RoHS Status: Exempt

COO (Country of Origin):
AT

Eaton MCB, 10A Current Rating, Type C Tripping Characteristics - 236285 PXL-C10/2


This MCB is a reliable miniature circuit breaker designed for domestic and commercial electrical installations. With a two-pole configuration and a current rating of 10A, it effectively protects electrical circuits from overloads and short circuits. The device measures 80mm in length and 35mm in width, making it an efficient option for DIN rail mounting.

Features & Benefits


• 10A circuit breaker protects circuits effectively
• Type C MCB allows for reliable current management
• Robust breaking capacity of 10 kA safeguards against faults
• Toggle switch for simple reset functionality
• Designed to operate in temperatures from -25°C to 55°C
• Compatible with multi-stranded and solid-core conductors

Applications


• Used with xPole series for reliable circuit protection
• Ideal for residential and commercial switchgear
• Suitable for integration into building management systems
• Enhances safety in automation and electrical panels

How does the breaking capacity enhance circuit safety?


The breaking capacity of 10 kA ensures that the MCB can effectively interrupt high fault currents, minimising damage and potential hazards during electrical faults.

What are the conductor cross-section capabilities?


It accommodates a maximum of 25 mm² for both solid-core and multi-stranded conductors, ensuring flexibility in installation options.

Can this circuit breaker be mounted in various orientations?


Although designed for DIN rail mounting, it is recommended to mount in the upright position for optimal performance and accessibility.

How is temperature stability managed within this MCB?


The design incorporates specifications that maintain safe operation up to 55°C, with current-carrying capacity reducing linearly with increasing temperature, thus protecting connected circuits.

Note

Eaton formerly known as Moeller

Standards

IEC / EN 60898
