Eaton xEffect FAZ Miniature Circuit Breaker, 4-Pole, 1.5 A, Type D, 400 V ac AC, 15 kA Breaking Capacity
- RS Stock No.:
- 257-030
- Mfr. Part No.:
- 279070 FAZ-D1,5/4
- Brand:
- Eaton
Subtotal (1 unit)*
£225.33
(exc. VAT)
£270.40
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 23 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £225.33 |
*price indicative
- RS Stock No.:
- 257-030
- Mfr. Part No.:
- 279070 FAZ-D1,5/4
- Brand:
- Eaton
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Eaton | |
| Number of Poles | 4 | |
| Product Type | Miniature Circuit Breaker | |
| Current Rating | 1.5 A | |
| Tripping Characteristics | Type D | |
| Rated AC Voltage | 400 V ac | |
| Mount Type | Top Hat Rail | |
| Breaking Capacity | 15kA | |
| Range | xEffect | |
| Series | FAZ | |
| IP Rating | IP20 | |
| Width | 72 mm | |
| Height | 75.5mm | |
| Depth | 80mm | |
| Standards/Approvals | RoHS, UL, CSA, EAN, EN45545-2, EN 63000:2018, IEC 61373, IEC/EN 60898, IEC/EN 60947-2 | |
| Select all | ||
|---|---|---|
Brand Eaton | ||
Number of Poles 4 | ||
Product Type Miniature Circuit Breaker | ||
Current Rating 1.5 A | ||
Tripping Characteristics Type D | ||
Rated AC Voltage 400 V ac | ||
Mount Type Top Hat Rail | ||
Breaking Capacity 15kA | ||
Range xEffect | ||
Series FAZ | ||
IP Rating IP20 | ||
Width 72 mm | ||
Height 75.5mm | ||
Depth 80mm | ||
Standards/Approvals RoHS, UL, CSA, EAN, EN45545-2, EN 63000:2018, IEC 61373, IEC/EN 60898, IEC/EN 60947-2 | ||
RoHS Status: Exempt
- COO (Country of Origin):
- RO
The Eaton Miniature Circuit Breaker from the Moeller series provides reliable overcurrent protection for industrial and commercial applications. Engineered to deliver excellent performance with its 4 pole design, it features a D characteristic curve, ensuring quick response to overload conditions. This product combines advanced technology with compact dimensions, making it an ideal choice for space constrained environments. With a wide ambient operating temperature range, it is designed to operate efficiently under varying conditions, ensuring your circuits remain safe from faults.
Compact design ensures efficient use of limited space
Wide operational temperature range accommodates diverse environments
RoHS compliant for environmentally friendly usage
Meets international safety standards for added assurance
User friendly installation simplifies setup and maintenance
