Eaton xEffect FAZ Miniature Circuit Breaker, 1-Pole, 1.5 A, Type D, 240 V ac AC, 60 V DC, 15 kA Breaking Capacity
- RS Stock No.:
- 248-707
- Mfr. Part No.:
- 102139 FAZ-D1,5/1-RT
- Brand:
- Eaton
Subtotal (1 unit)*
£80.08
(exc. VAT)
£96.10
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 06 April 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £80.08 |
*price indicative
- RS Stock No.:
- 248-707
- Mfr. Part No.:
- 102139 FAZ-D1,5/1-RT
- Brand:
- Eaton
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Eaton | |
| Product Type | Miniature Circuit Breaker | |
| Number of Poles | 1 | |
| Current Rating | 1.5 A | |
| Tripping Characteristics | Type D | |
| Rated AC Voltage | 240 V ac | |
| Rated DC Voltage | 60 V | |
| Breaking Capacity | 15kA | |
| Mount Type | Top Hat Rail | |
| Range | xEffect | |
| Series | FAZ | |
| Terminal Type | Twin-Purpose Terminal | |
| IP Rating | IP20, IP40 | |
| Depth | 70.5mm | |
| Height | 75.5mm | |
| Width | 17.7 mm | |
| Standards/Approvals | IEC EN 60947-2, CE, CSA, CSA C22.2 No. 5, CSA-C22.2 No. 5-09, CSA Class No. 1432-01, CSA File No. 204453, EN45545-2, IEC 60947-2, IEC 61373, North America UL, UL 489, UL Category Control Number DIVQ, UL File No. E235139 | |
| Select all | ||
|---|---|---|
Brand Eaton | ||
Product Type Miniature Circuit Breaker | ||
Number of Poles 1 | ||
Current Rating 1.5 A | ||
Tripping Characteristics Type D | ||
Rated AC Voltage 240 V ac | ||
Rated DC Voltage 60 V | ||
Breaking Capacity 15kA | ||
Mount Type Top Hat Rail | ||
Range xEffect | ||
Series FAZ | ||
Terminal Type Twin-Purpose Terminal | ||
IP Rating IP20, IP40 | ||
Depth 70.5mm | ||
Height 75.5mm | ||
Width 17.7 mm | ||
Standards/Approvals IEC EN 60947-2, CE, CSA, CSA C22.2 No. 5, CSA-C22.2 No. 5-09, CSA Class No. 1432-01, CSA File No. 204453, EN45545-2, IEC 60947-2, IEC 61373, North America UL, UL 489, UL Category Control Number DIVQ, UL File No. E235139 | ||
- COO (Country of Origin):
- RO
The Eaton Miniature Circuit Breaker from the Moeller series specifically designed for industrial and advanced commercial applications. With its robust construction and compliance with international standards, it ensures optimal protection against overloads and short circuits. Tailored for North American specifications, the breaker seamlessly integrates into various switchgear configurations while offering exceptional functionality. Featuring a single pole design with a D tripping characteristic, it operates efficiently at a rated current of 1.5 A.
Designed for adherence to RoHS and CE compliance standards
Features a sleek IP20 degree of protection for enhanced safety
Utilises twin purpose terminals for versatile conductor connections
Facilitates easy mounting on top hat rails to simplify installation processes
Includes built in safety features against finger and hand touch risks
Offers exceptional lifespan capabilities of up to 20000 electrical operations
