Eaton xEffect FAZ Miniature Circuit Breaker, 2-Pole, 25 A, Type C, 440 V ac AC, 60 V DC, 7.5 kA Breaking Capacity
- RS Stock No.:
- 255-775
- Mfr. Part No.:
- 240863 FAZT-C25/2
- Brand:
- Eaton
Subtotal (1 unit)*
£150.86
(exc. VAT)
£181.03
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 23 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £150.86 |
*price indicative
- RS Stock No.:
- 255-775
- Mfr. Part No.:
- 240863 FAZT-C25/2
- Brand:
- Eaton
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Eaton | |
| Product Type | Miniature Circuit Breaker | |
| Number of Poles | 2 | |
| Current Rating | 25 A | |
| Tripping Characteristics | Type C | |
| Rated AC Voltage | 440 V ac | |
| Rated DC Voltage | 60 V | |
| Breaking Capacity | 7.5kA | |
| Range | xEffect | |
| Series | FAZ | |
| Terminal Type | Twin-Purpose Terminal | |
| IP Rating | IP20 | |
| Standards/Approvals | IEC/EN 60947-2 EN45545-2 IEC 61373 | |
| Width | 36 mm | |
| Depth | 80mm | |
| Height | 75.5mm | |
| Select all | ||
|---|---|---|
Brand Eaton | ||
Product Type Miniature Circuit Breaker | ||
Number of Poles 2 | ||
Current Rating 25 A | ||
Tripping Characteristics Type C | ||
Rated AC Voltage 440 V ac | ||
Rated DC Voltage 60 V | ||
Breaking Capacity 7.5kA | ||
Range xEffect | ||
Series FAZ | ||
Terminal Type Twin-Purpose Terminal | ||
IP Rating IP20 | ||
Standards/Approvals IEC/EN 60947-2 EN45545-2 IEC 61373 | ||
Width 36 mm | ||
Depth 80mm | ||
Height 75.5mm | ||
RoHS Status: Exempt
- COO (Country of Origin):
- RO
The Eaton Moeller series xEffect FAZ T MCB is a state of the art miniature circuit breaker designed to deliver robust performance in both industrial and advanced commercial applications. With its two pole configuration and a tripping characteristic of C, this circuit breaker is tailored for reliable operation under varying load conditions. The compact dimensions and efficient thermal performance make it an excellent choice for tight installations, while the IP20 degree of protection ensures safety against accidental contact. Its ability to operate effectively at extreme temperatures further underscores its versatility, making it suitable for a range of scenarios. The incorporation of quick attachment methods and twin purpose terminals simplifies installation and maintenance, enhancing user experience. Overall, this product exemplifies excellence in functionality and design for demanding environments.
Optimised thermal performance for reduced heat build up
Versatile design compatible with a wide range of applications
Quick attachment method facilitates effortless installation
Designed to meet stringent compliance and certification standards
Enhanced safety features prevent accidental electrical contact
