Eaton xEffect FAZ Miniature Circuit Breaker, 1-Pole, 12 A, Type C, 230 V ac AC, 60 V DC, 7.5 kA Breaking Capacity
- RS Stock No.:
- 254-307
- Mfr. Part No.:
- 240804 FAZT-C12/1
- Brand:
- Eaton
Subtotal (1 unit)*
£52.62
(exc. VAT)
£63.14
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 20 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £52.62 |
*price indicative
- RS Stock No.:
- 254-307
- Mfr. Part No.:
- 240804 FAZT-C12/1
- Brand:
- Eaton
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Eaton | |
| Product Type | Miniature Circuit Breaker | |
| Number of Poles | 1 | |
| Current Rating | 12 A | |
| Tripping Characteristics | Type C | |
| Rated AC Voltage | 230 V ac | |
| Rated DC Voltage | 60 V | |
| Breaking Capacity | 7.5kA | |
| Mount Type | Top Hat Rail | |
| Range | xEffect | |
| Series | FAZ | |
| Terminal Type | Twin-Purpose Terminal | |
| IP Rating | IP20 | |
| Standards/Approvals | IECEN 6149, IECEN 60947, IEC 617, EN 608981:019, EN 6000:018, EN45545, EAN, RoHS | |
| Depth | 80mm | |
| Width | 17.7 mm | |
| Height | 75.5mm | |
| Select all | ||
|---|---|---|
Brand Eaton | ||
Product Type Miniature Circuit Breaker | ||
Number of Poles 1 | ||
Current Rating 12 A | ||
Tripping Characteristics Type C | ||
Rated AC Voltage 230 V ac | ||
Rated DC Voltage 60 V | ||
Breaking Capacity 7.5kA | ||
Mount Type Top Hat Rail | ||
Range xEffect | ||
Series FAZ | ||
Terminal Type Twin-Purpose Terminal | ||
IP Rating IP20 | ||
Standards/Approvals IECEN 6149, IECEN 60947, IEC 617, EN 608981:019, EN 6000:018, EN45545, EAN, RoHS | ||
Depth 80mm | ||
Width 17.7 mm | ||
Height 75.5mm | ||
RoHS Status: Exempt
- COO (Country of Origin):
- RO
The Eaton Moeller series xEffect FAZ T miniature circuit breaker is engineered for reliability in demanding industrial environments. Designed with precision, this single pole unit features a tripping characteristic of 'C' for optimal protection against overloads and short circuits. With a compact footprint, it easily fits into standard switching equipment while offering robust performance under various electrical loads. Built to meet stringent compliance standards, it ensures safety and longevity in operation. Its ability to function under a wide temperature range makes it ideal for diverse applications. The FAZ T series brings together innovative design with the latest technology, representing a significant advancement in electrical safety devices.
Enjoy peace of mind with RoHS compliance ensuring environmentally friendly materials
Experience quick installation with top hat rail mounting for efficient setup
Benefit from finger and hand touch safe terminals prioritising user safety
Utilise compact dimensions without compromising on performance or capability
Leverage a high rated short circuit breaking capacity for superior electrical protection
Ensure operational reliability across a range of ambient temperatures from 25 °C to 75 °C
Rely on a lifespan of 4000 electrical operations maximising product longevity
Take advantage of easy access to technical documentation for seamless installation and maintenance
