Eaton xEffect FAZ MCB, 3+N, 12A Curve B, 440V AC, 60V DC, 7.5 kA Breaking Capacity
- RS Stock No.:
- 254-196
- Mfr. Part No.:
- 241090 FAZT-B12/3N
- Brand:
- Eaton
Subtotal (1 unit)*
£176.87
(exc. VAT)
£212.24
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 01 December 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 + | £176.87 |
*price indicative
- RS Stock No.:
- 254-196
- Mfr. Part No.:
- 241090 FAZT-B12/3N
- Brand:
- Eaton
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Eaton | |
Number of Poles | 3+N | |
Current Rating | 12A | |
Tripping Characteristics | Type B | |
Rated AC Voltage | 440V | |
Rated DC Voltage | 60V | |
Breaking Capacity at Maximum Voltage Rating | 7.5 kA | |
Range | xEffect | |
Series | FAZ | |
Select all | ||
---|---|---|
Brand Eaton | ||
Number of Poles 3+N | ||
Current Rating 12A | ||
Tripping Characteristics Type B | ||
Rated AC Voltage 440V | ||
Rated DC Voltage 60V | ||
Breaking Capacity at Maximum Voltage Rating 7.5 kA | ||
Range xEffect | ||
Series FAZ | ||
- COO (Country of Origin):
- RO
The Eaton Moeller series xEffect FAZ T MCB is a cutting edge miniature circuit breaker designed to deliver superior protection in industrial and advanced commercial applications. Engineered with a robust tripping characteristic of B, and rated for a current of 12 A, this device ensures reliable performance under varying loads. With its compact construction of 80 mm in width and a height of 75.5 mm, it seamlessly integrates into standard electrical installations. The MCB boasts compliance with stringent international standards including RoHS, IEC/EN 60947 2, and EN45545 2, providing peace of mind for safety and reliability. Moreover, the degree of protection rated at IP20 makes it suitable for diverse environments, while its quick attachment system simplifies installation. Benefit from a lifespan of 4000 electrical operations and 10000 mechanical operations, making it a durable choice for long term use.
Compact design allowing for space efficient installations
Quick attachment system simplifies mounting on top hat rails
Designed for reliability in industrial and commercial environments
Complies with multiple stringent safety and performance standards
Ideal for applications requiring effective overcurrent protection
Robust mechanical and electrical lifespan ensures long term reliability
Managed temperature rises enhance overall device safety
Advanced EMC characteristics ensure minimal interference
Built in safety provisions protect against accidental contact
Versatile mounting position allows for adaptable installations
Quick attachment system simplifies mounting on top hat rails
Designed for reliability in industrial and commercial environments
Complies with multiple stringent safety and performance standards
Ideal for applications requiring effective overcurrent protection
Robust mechanical and electrical lifespan ensures long term reliability
Managed temperature rises enhance overall device safety
Advanced EMC characteristics ensure minimal interference
Built in safety provisions protect against accidental contact
Versatile mounting position allows for adaptable installations
