Eaton xEffect FAZ Miniature Circuit Breaker, 3-Pole, 6 A, Type C, 415 V ac AC, 60 V dc DC, 10 kA Breaking Capacity
- RS Stock No.:
- 241-221
- Mfr. Part No.:
- 102284 FAZ-C6/3-RT
- Brand:
- Eaton
Subtotal (1 unit)*
£225.33
(exc. VAT)
£270.40
(inc. VAT)
FREE delivery for orders over £50.00
Stocked by manufacturer
- Ready to ship from 04 May 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £225.33 |
*price indicative
- RS Stock No.:
- 241-221
- Mfr. Part No.:
- 102284 FAZ-C6/3-RT
- Brand:
- Eaton
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Eaton | |
| Number of Poles | 3 | |
| Product Type | Miniature Circuit Breaker | |
| Current Rating | 6 A | |
| Tripping Characteristics | Type C | |
| Rated AC Voltage | 415 V ac | |
| Rated DC Voltage | 60 V dc | |
| Mount Type | Top Hat Rail | |
| Breaking Capacity | 10kA | |
| Range | xEffect | |
| Series | FAZ | |
| Terminal Type | Twin-Purpose Terminal | |
| IP Rating | IP20, IP40 | |
| Depth | 70.5mm | |
| Standards/Approvals | UL 489, CE, CSA, CSA C. . 5, CSAC. . 509, CSA Class . 1401, CSA File . 0445, EN45545, EN 60947, IEC, IEC 60947, IEC 617, UL, UL File . E519 | |
| Width | 53.1 mm | |
| Height | 75.5mm | |
| Select all | ||
|---|---|---|
Brand Eaton | ||
Number of Poles 3 | ||
Product Type Miniature Circuit Breaker | ||
Current Rating 6 A | ||
Tripping Characteristics Type C | ||
Rated AC Voltage 415 V ac | ||
Rated DC Voltage 60 V dc | ||
Mount Type Top Hat Rail | ||
Breaking Capacity 10kA | ||
Range xEffect | ||
Series FAZ | ||
Terminal Type Twin-Purpose Terminal | ||
IP Rating IP20, IP40 | ||
Depth 70.5mm | ||
Standards/Approvals UL 489, CE, CSA, CSA C. . 5, CSAC. . 509, CSA Class . 1401, CSA File . 0445, EN45545, EN 60947, IEC, IEC 60947, IEC 617, UL, UL File . E519 | ||
Width 53.1 mm | ||
Height 75.5mm | ||
RoHS Status: Exempt
- COO (Country of Origin):
- RO
The Eaton Miniature Circuit Breaker from the Moeller series is engineered to provide reliable circuit protection for industrial and advanced commercial applications. This robust solution ensures optimal safety with a tripping characteristic of C, designed to handle a rated current of 6 A effortlessly. The miniature circuit breaker offers seamless integration into your electrical system with its three pole configuration, making it suitable for various feeder and branch circuits.
Designed for industrial and advanced commercial applications
Complies with RoHS standards for environmental safety
Compact dimensions allow for space efficient installations
Constructed to withstand environmental factors with IP20 and IP40 protection ratings
