Renesas Electronics ISL3177EIBZ Line Transceiver, 8-Pin MSOP
- RS Stock No.:
- 196-8623
- Mfr. Part No.:
- ISL3177EIBZ
- Brand:
- Renesas Electronics
Bulk discount available
Subtotal (1 tube of 98 units)*
£111.034
(exc. VAT)
£133.28
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 3,234 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Tube* |
---|---|---|
98 - 392 | £1.133 | £111.03 |
490 - 882 | £1.076 | £105.45 |
980 + | £0.963 | £94.37 |
*price indicative
- RS Stock No.:
- 196-8623
- Mfr. Part No.:
- ISL3177EIBZ
- Brand:
- Renesas Electronics
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Renesas Electronics | |
IC Type | Cable Transceiver IC | |
Number of Transmitters | RS-422, RS-485 | |
Package Type | MSOP | |
Pin Count | 8 | |
Select all | ||
---|---|---|
Brand Renesas Electronics | ||
IC Type Cable Transceiver IC | ||
Number of Transmitters RS-422, RS-485 | ||
Package Type MSOP | ||
Pin Count 8 | ||
The Renesas ISL317xE are ±15kV IEC61000 ESD protected, 3.3V powered single transceivers that meet both the RS-485 and RS-422 standards for balanced communication. These devices have very low bus currents (+125μA/-100μA), so they present a true 1/8 unit load to the RS-485 bus. This allows up to 256 transceivers on the network without violating the RS-485 specifications 32 unit load maximum, and without using repeaters.
-7V to +12V common-mode input/output voltage range
It has half and full duplex pinouts
It has three state Rx and Tx outputs available
There is current limiting and thermal shutdown for driver overload protection
It has half and full duplex pinouts
It has three state Rx and Tx outputs available
There is current limiting and thermal shutdown for driver overload protection
