RS PRO Lever Limit Switch, 1 NO/1 NC, IP67, Die Cast Zinc Housing, 250V ac, 3.10A

RS Stock No.:: 269-5449
Brand:: RS PRO

RS PRO Lever Limit Switch, 1 NO/1 NC, IP67, Die Cast Zinc Housing, 250V ac, 3.10A

Subtotal (1 unit)*

£74.52

(exc. VAT)

£89.42

(inc. VAT)

FREE delivery for orders over £60.00

In Stock

87 unit(s) ready to ship
Plus 15 unit(s) ready to ship from another location
Plus 56 unit(s) shipping from 20 July 2026

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Units	Per unit
1 +	£74.52

*price indicative

RS Stock No.:: 269-5449
Brand:: RS PRO

Specifications

Technical Reference

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	RS PRO
	Actuator Type	Lever
	Product Type	Limit Switch
	Contact Configuration	1 NO/1 NC
	IP Rating	IP67
	Housing Material	Die Cast Zinc
	Contact Type	Snap Action
	Terminal Type	Screw
	Switching Current	3.10A
	Switching AC Voltage	250V ac
	Switching DC Voltage	250V dc
	Minimum Operating Temperature	-25°C
	Maximum Operating Temperature	85°C
	Width	1640mm
	Standards/Approvals	IEC 60947-5-1/EN 60947-5-1/UL508
	Length	57.5mm
	Depth	44mm
	Hazardous Area Certification	UL, CSA
	Mechanical Life	10Operations
	Mounting Orientation	Side
	Operating Force	11N
	Conduit Entry	Pg 13.5 Cable Gland

	Select all
	Brand RS PRO
	Actuator Type Lever
	Product Type Limit Switch
	Contact Configuration 1 NO/1 NC
	IP Rating IP67
	Housing Material Die Cast Zinc
	Contact Type Snap Action
	Terminal Type Screw
	Switching Current 3.10A
	Switching AC Voltage 250V ac
	Switching DC Voltage 250V dc
	Minimum Operating Temperature -25°C
	Maximum Operating Temperature 85°C
	Width 1640mm
	Standards/Approvals IEC 60947-5-1/EN 60947-5-1/UL508
	Length 57.5mm
	Depth 44mm
	Hazardous Area Certification UL, CSA
	Mechanical Life 10Operations
	Mounting Orientation Side
	Operating Force 11N
	Conduit Entry Pg 13.5 Cable Gland

COO (Country of Origin):: CN

RS PRO Zinc, Lever Limit Switch, SPDT, 1NO/1NC, Snap Action, Screw Terminal, Rated 10 A, 600 V ac, M20 Conduit

From RS PRO this is the global styed safety die cast zinc limit switch range designed and engineered to provide excellent protection as a safe and reliable limit switch within many mechanical devices. As the limit switch is made from die cast zinc it is hard wearing, has IP67 rated protection making the limit switch suitable for indoor and outdoor use.

Adding to the RS PRO compact precision limit switch features the contact block is interchangeable, is easily wired with screw terminals with self-lifting clamps. The limit switch has 4 x 90° actuator positions plus a single M20 conduit entry. The limit switch provides a service life of 10,000,000 mechanical operations and 500,000 electrical all conforming to international standards.

Features & Benefits

Lever limit switch

Snap Action

Made from Die Cast zinc

Screw terminals with self-lifting clamps

Increased wiring space

Earth grounding surface same level as switching

Fine adjustment of switching using adjustment screw

Easily interchangeable contact block

Galvanically separated contacts

Positive opening of NC contacts

4 x 90° Actuator positions

M20 Cable entry

1NO/1NC

Operating temperature range -25°C to +80°C

Operating speed 0.05 mm, 2 m per sec

Mechanical service life 10 million operations

Electrical service life of 500,000 operations

Insulation resistance 100MΩ at 500 V dc

Dielectric strength 1000 V ac, 1 minute between non-continuous terminals

Dielectric strength 2500 V ac, 1 minute between each terminal and ground

Electrical rating AC15 – A600, DC13 – Q300

IP67 Rated, UL, CSA, IEC 60947-5-1, EN 60947-5-1, UL508

What is a Limit Switch?

A Limit Switch is especially important within industrial automation and control systems providing essential information and safety measures. Designed to detect the presence or absence of an object or to monitor the position of a moving part within an industrial process, machine, or equipment. A Limit Switch ensures that a component will stop, start, or change direction when required.

Benefits and Types of Limit Switches

There are many benefits in using limit switches within mechanical and industrial environments as they provide precise control, safety, and feedback.

Position sensing limit switches accurately sense the position of a mechanical component

Safety limit switches, important within industrial processes, preventing accidents and damage when something unsafe it detected by signalling a system to stop

Automation limit switches are vital within automation and control as the control machinery, equipment and processes providing important feedback to a control system

Mechanical actuation limit switches operate by physical contact with a moving part or object triggering the switch to change its state

The switches have electrical contacts that change their position when actuated, normally open (NO), normally closed (NC) or both NO+NC

Limit switches are a hard-wearing reliable component specially designed to stand up to mechanical wear, the environment, and extreme industrial conditions

Limit switches are available in various actuator types suitable for different applications, no matter the job there is a limit switch available for your requirements

Flexible and easy to install and integrate into existing systems, easily mounted reducing any equipment downtime

Limit switches provide you with feedback allowing you to identify and deal with any problems within a system
