Wieland RST 08i2/3 Series Circular Connector, 2-Pole, Female, Panel Mount, 8A, IP66, IP68, IP69
- RS Stock No.:
- 187-4834
- Mfr. Part No.:
- 41.021.4043.9
- Brand:
- Wieland
Bulk discount available
Subtotal (1 box of 50 units)*
£195.35
(exc. VAT)
£234.40
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 22 December 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Box* |
|---|---|---|
| 50 - 50 | £3.907 | £195.35 |
| 100 - 100 | £3.689 | £184.45 |
| 150 + | £3.607 | £180.35 |
*price indicative
- RS Stock No.:
- 187-4834
- Mfr. Part No.:
- 41.021.4043.9
- Brand:
- Wieland
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Wieland | |
| Pole Format | 2 | |
| Series | RST 08i2/3 | |
| Gender | Female | |
| Plug/Socket | Socket | |
| Colour | Blue | |
| Type | Circular Connector | |
| Mounting Type | Panel Mount | |
| Current Rating | 8A | |
| Voltage Rating | 250 V, 400 V | |
| IP Rating | IP66, IP68, IP69 | |
| Wire Size | 0.2 → 1.0 mm² | |
| Contact Material | CuZn | |
| Contact Plating | Silver | |
| Diameter | 19.2mm | |
| Termination Method | Screw | |
Select all | ||
|---|---|---|
Brand Wieland | ||
Pole Format 2 | ||
Series RST 08i2/3 | ||
Gender Female | ||
Plug/Socket Socket | ||
Colour Blue | ||
Type Circular Connector | ||
Mounting Type Panel Mount | ||
Current Rating 8A | ||
Voltage Rating 250 V, 400 V | ||
IP Rating IP66, IP68, IP69 | ||
Wire Size 0.2 → 1.0 mm² | ||
Contact Material CuZn | ||
Contact Plating Silver | ||
Diameter 19.2mm | ||
Termination Method Screw | ||
- COO (Country of Origin):
- DE
Wieland RST Lighting Connector
The RST Series by Wieland has four series available, offering a complete electrical installation system to meet different requirements. All connectors are fitter-friendly and offer flexible and easy installation, to minimise incorrect connections. The RST Micro is a miniature connector for LED lamps and signals, optimised for the interfaces between voltage or current sources and LED modules to offer an ideal solution for dimming or DMX applications.
Features and Benefits
• The RST Micro series offers integrated device protection, with an internal water stop with barrier seal contacts. This function prevents water from entering the wiring system and causing moisture damage to wires in incorrectly executed installations.
• The RST Micro installation system is comprised of connectors, M14 device connectors, pre-assembled conductors and splitters.
• The lighting connectors are available with either 2 or 3 poles.
• The RST Micro installation system is comprised of connectors, M14 device connectors, pre-assembled conductors and splitters.
• The lighting connectors are available with either 2 or 3 poles.
Applications and Uses:
• Electrical installations
• Lighting applications such as LED signals
• Lighting applications such as LED signals
RST 08i3/2 device connection M14, 2 pole, female, screw connection, application 250V/400V, 8A, coding colour light blue
Gesis RST Connector Range
