SICK L29S Series Light Curtain Sender, 1 Beam(s)
- RS Stock No.:
- 285-9640
- Mfr. Part No.:
- L29S-3D3430
- Brand:
- SICK
Subtotal (1 unit)*
£74.26
(exc. VAT)
£89.11
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- 4 unit(s) shipping from 18 November 2025
- Plus 999,999,995 unit(s) shipping from 11 December 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £74.26 |
*price indicative
- RS Stock No.:
- 285-9640
- Mfr. Part No.:
- L29S-3D3430
- Brand:
- SICK
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | SICK | |
| Series | L29S | |
| Component Type | Sender | |
| Safety Type | 2 | |
| SIL IEC 61508 | SIL 1 | |
| PL EN ISO 13849-1 | PL c | |
| Number of Beams | 1 | |
| Maximum Scanning Distance | 6m | |
| Maximum Response Time | 0.54 ms | |
| Height | 50mm | |
| Length | 23.6mm | |
| Supply Voltage | 24 V dc | |
| Dimensions | 12.2 x 50 x 23.6 mm | |
| Width | 12.2mm | |
| Terminal Type | M12 Connector | |
Select all | ||
|---|---|---|
Brand SICK | ||
Series L29S | ||
Component Type Sender | ||
Safety Type 2 | ||
SIL IEC 61508 SIL 1 | ||
PL EN ISO 13849-1 PL c | ||
Number of Beams 1 | ||
Maximum Scanning Distance 6m | ||
Maximum Response Time 0.54 ms | ||
Height 50mm | ||
Length 23.6mm | ||
Supply Voltage 24 V dc | ||
Dimensions 12.2 x 50 x 23.6 mm | ||
Width 12.2mm | ||
Terminal Type M12 Connector | ||
- COO (Country of Origin):
- DE
Overview
The L29 single-beam photoelectric safety switch consists of a sender and receiver. The test input of the sender allows direct functional tests. Performance level PL c in acc. with EN ISO 13849-1 or Type 2 in acc. with IEC 61496 can be achieved in conjunct
Based on the rugged VISTAL™ housing and the high enclosure rating the L29 is suitable for applications with rough environmental conditions. Due to the very small size the L29 can easily be integrated in applications with limited installation space.
At a glance
Type 2 (IEC 61496), SIL1 (IEC 61508), PL c (EN ISO 13849), only in conjunction with an external test device of the product family Flexi Classic (UE410-MU)
Very small housing dimensions (50 mm x 23,6 mm x 12,2 mm)
Ultra-rugged VISTAL™ housing
Ecolab tested
Very small housing dimensions (50 mm x 23,6 mm x 12,2 mm)
Ultra-rugged VISTAL™ housing
Ecolab tested
Your Benefit
Easy integration due to very small design
Reliability in installation and operation due to rugged VISTAL™ housing
Very good material resistance, tested based on the Ecolab testing method
Well suited to withstand extreme ambient conditions such as heat, co
Reliability in installation and operation due to rugged VISTAL™ housing
Very good material resistance, tested based on the Ecolab testing method
Well suited to withstand extreme ambient conditions such as heat, co
Applications
Packaging industry: protecting small gaps
Automatic gates: e.g., protecting the closing edge on roller doors
Automatic gates: e.g., protecting the closing edge on roller doors
Note
Product details cover the whole product family. For details on the specifications for this individual product, please refer to the datasheet.
